VS-RTD2556HM-V1 + NV126B5M-N41 - 12.6 inch

VSDISPLAY VS-RTD2556HM-V1 + NV126B5M-N41 - 12.6 inch

Unavailable

Key Features

HDMI ports quantity: 2
Weight: 560g
Batteries included: No
Display diagonal: 12.6"
Display resolution: 1920 x 515pixels

Specifications

Features

Display diagonal

12.60 "

Weight & dimensions

Weight

560 g

Display

Display resolution

1920 x 515 pixels

Packaging content

Batteries included

✗

Ports & interfaces

HDMI ports quantity

Product Details

LCD Controller Board: Board Work for 30Pin EDP LCD Screen Input Power Adapter: 12Vdc More than 2A. Come In Standby Model When Not Input Signal Standby Model <0.3W Audio Output: Earphone OSD: Brightness Contrast VOL+ VOL- Language And So On Language: English French German Spanish Italian And So On Board Size: 82mm x 60mm x 5mm 12.6" NV126B5M-N41 1920X515 LCD Screen: Display New Mode ADS, Normally Black, Transmissive Resolution 1920RGB)×515 Outline Size 315.61×94.02×5.3(H×V×D) Display Area 309.31×82.97 (H×V) Brightness 250 cd/m² (Typ.) Contrast Ratio 1200:1 (Typ.) (TM) Viewing Angle 85/85/85/85 (Typ.)(CR≥10) [Left / Right / Up / Down] Signal Interface eDP (2 Lanes), Connector, 40pins Backlight WLED Input Voltage 3.3V (Typ.) Packing list: 1× LCD Controller VS-RTD2556HM-V1 1× 12.6inch NV126B5M-N41 1920X515 IPS Capacitive Touch Screen 1× Signal Cable 1× Keyboard With Cable
