VS-TY2660H-V812 + TB070-I5024H45C-02 - SVGA Wide 7 Inches

VSDISPLAY VS-TY2660H-V812 + TB070-I5024H45C-02 - SVGA Wide 7 Inches

Name: VSDISPLAY VS-TY2660H-V812 + TB070-I5024H45C-02 - SVGA Wide 7 Inches
Brand: VSDISPLAY
SKU: 394924
Availability: InStock

Best offer

AED

256⁰⁰

Key Features

Aspect ratio: 16:9
Native aspect ratio: 16:9
Display diagonal: 7"

Specifications

Features

Display diagonal

7 "

Aspect ratio

16:9

Display

Native aspect ratio

16:9

Product Details

LCD Controller Board: LCD Board Work for 50P TTL Interface LCD Screen Power Connector: PH2.0 Micro USB Input Power Adapter: 5Vdc More than 2A Mirco-USB Connector Support 5V 1A Power For Connector Come In Standby Model When Not Input Signal Standby Model <1W Video Input: Audio: Earphone OSD: Brightness Contrast Auto Language And So On Language: English French German Spanish Italian And So On Board Size: 88mm x 53mm x 7mm 7" TB070-I5024H45C-02 1024X600 IPS LCD Screen: Display Mode IPS, Normally Black, Transmissive Resolution 1024RGB)×600 Outline Size 164.9× 100×3.5 (H×V×D) Display Area 154.21 × 85.92 (H×V) Brightness 400 cd/m² (Typ.) Contrast Ratio 800:1 (Typ.) (TM) Viewing Angle 85/85/85/85 (Typ.)(CR≥10) [Left / Right / Up / Down] Signal Interface Parallel RGB (1 ch, 8-bit) , 50 pins , FPC Backlight WLED Input Voltage 3.3V (Typ.) Packing list : 1× LCD Controller Board VS-TY2660H-V812 1× 7inch TB070-I5024H45C-02 1024X600 IPS LCD Screen 1× USB Power Cable 1× Mirco-USB Power Cable 1× Keyboard With Cable
