VSDISPLAY LQ091B1LW01 - 9.1" + VS-TY2660H-V818

LCD Controller Board: HDMI USB LCD Controller Board Work for LVDS 40Pin TTL LCD Screen Input Power Adapter: 12Vdc More than 2A.(9~14Vdc) Come In Standby Model When Not Input Signal Standby Model <1W Video Input: HDMI1.4 USB USB Port: Support Video Play Support WIFI Module Support Connect Keyboard and mouse Support 5Vdc 500mA output Support OS Android Screen projection via USB Cable or wifi Module Audio Input: HDMI Audio Output: Earphone connector Speaker (4Pin 1.25mm Pitch 8ohm 2W or 4ohm 2W) OSD: Brightness Contrast Auto Language And So On Language: English French German Spanish Italian And So On Board Size: 74mm x 53mm x 12mm 9.1" LQ091B1LW01 822X260 LCD Screen: Display Mode TN, Normally White, Transmissive Resolution 822RGB)×260 Outline Size 240× 86×10.5(H×V×D) Display Area 219.5× 69.4 (H×V) Brightness 380 cd/m² (Typ.) Contrast Ratio 800:1 (Typ.) (TM) Viewing Angle 85/85/85/85 (Typ.)(CR≥10) [Left / Right / Up / Down] Signal Interface LVDS (1 ch, 8-bit) , 30 pins , Connector Backlight WLED Input Voltage 3.3V (Typ.) Packing list: 1× HDMI Audio LCD Controller Board VS-TY2660H-V818 1× 9.1inch LQ091B1LW01 822X260 LCD Screen 1× LVDS Cable 1× Keyboard With Cable 1× Remote Control (Battery Not included)
