Hikvision DS-2CD2121G0-I

Name: Hikvision DS-2CD2121G0-I
Brand: Hikvision
SKU: 357512

Best offer

AED

248⁰⁰

Key Features

Camera tilt control: Yes
Thermal module: Yes
Camera pan control: Yes
Noise reduction technology: 3D noise reduction
Lens viewing angle, vertical: 62°°
Lens viewing angle, diagonal: 90°°
Power consumption (Power over Ethernet (PoE)): 8.5W
Infrared (IR) cut-off filter: Yes
Digital watermark: Yes
Type: IP security camera
Active tampering alarm: Yes
Mirror: Yes
Motion sensor: Yes
Sample rate: 48kHz
Supported graphics resolutions: 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 320 x 240, 352 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA), 704 x 576

Specifications

Features

Web browser

✓

Voice codecs

G.711, G.722.1, G.726, MP2L2, PCM

Number of sensors

Audio formats supported

LPCM, MP3

Card reader integrated

✓

Quality of Service (QoS) support

✓

Maximum memory card size

128 GB

Password protection

✓

Video motion detection

✓

Languages support

Traditional Chinese, Danish, German, Dutch, Finnish, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, RON, Russian, SER, Slovak, Slovenian, SPA, Swedish, Thai, Turkish

Number of languages

Connectivity technology

Wired

Product colour

Black

Video streaming

✓

Digital watermark

✓

Type

IP security camera

Active tampering alarm

✓

Mirror

✓

Motion sensor

✓

Sample rate

48 kHz

Supported graphics resolutions

1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 320 x 240, 352 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA), 704 x 576

Packaging data

Package weight

202 g

Package height

99 mm

Package depth

110 mm

Package width

150 mm

Weight & dimensions

Weight

93 g

Height

143 mm

Depth

31 mm

Width

31 mm

Diameter

119 mm

Length

92 mm

Management features

Web-based management

✓

Behavior analysis

Intrusion detection, Line crossing detection, Object removal detection, Unattended baggage detection

Power

Power consumption (typical)

4.80 W

AC input voltage

24 V

Power consumption (max)

3 W

DC output current

0.30 A

Power source type

DC output voltage

Power consumption (Power over Ethernet (PoE))

8.50 W

Performance

Camera pan control

✓

Thermal module

✓

Other features

Noise reduction

✓

Ergonomics

Angle of rotation

355 °

Storage

Compatible memory cards

MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC

Built-in HDD

✗

Design

International Protection (IP) code

IP67

IK code

IK10

Housing material

Aluminium, Metal

Placement supported

Indoor, Indoor/Outdoor, Outdoor

Reset button

✓

Mounting type

Ceiling/Wall

Form factor

Box

Packaging content

Manual

✓

Network

Wi-Fi

✗

Bluetooth

✗

Networking standards

IEEE 802.1x, IEEE 802.3af

Supported network protocols

802.1X, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv6, NTP, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, SSL/TLS, TCP/IP, UDP, UPnP, UPnP™

Cabling technology

10/100Base-T(X)

Ethernet interface type

Fast Ethernet

Ethernet LAN

✓

Ports & interfaces

Interface

RJ-45

RS-232 ports

Ethernet LAN (RJ-45) ports

Headphone outputs

Microphone in

✓

Composite video out

RS-485 ports

HDMI ports quantity

Operational conditions

Operating relative humidity (H-H)

0 - 95 %

Technical details

Anti-flicker

✓

Compliance certificates

RoHS

Lens system

Maximum aperture number

1.60

Number of lenses

Fixed focal length

2.80 mm

Noise reduction technology

3D noise reduction

Video

Video compression formats

H.264, H.265, M-JPEG

Video formats supported

H.264, H.265, M-JPEG

Frame rate

30 fps

Image quality adjustment

Brightness, Contrast, DNR, Saturation, Sharpness

Privacy masking

✓

Security

IP address filtering

✓

Heartbeat

✓

HTTPS encryption

✓

Camera

Day/night mode

✓

Back Light Compensation (BLC)

✓

Camera shutter speed

1/100 s

3D NR (Noise Reduction)

✓

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Region of Interest (ROI) encoding

✓

Total megapixels

2 MP

Number of cameras

Bit rate

32 Kbps - 8 Mbps

Sensor type

CMOS

Lens viewing angle, horizontal

114°

Progressive scan

✓

White balance

Manual

Full HD

✓

Wide Dynamic Range (WDR)

✓

Intelligent Video Surveillance (IVS) system features

Defocus, Face detection, Intrusion, Scene change

Alarm input/output

✓

Highlight Compensation (HLC)

✓

Lens viewing angle, diagonal

90°

Lens viewing angle, vertical

62°

Camera tilt control

✓

Pan-tilt unit

Tilt angle range

0 - 75 °

Pan range

0 - 355 °

Image sensor

Maximum resolution

1920 x 1080 pixels

Minimum illumination

0.01 lx

Infrared (IR) cut-off filter

✓

Night vision

✓

LED type

Night vision distance

30 m

Infra-red wavelength

850 nm

Product Details

1/2.7'' progressive scan CMOS 1920*1080@30fps 120dB WDR 3D DNR H.265+,H.265,H.264+,H.264 6 behavior analyses, 2 exception detections and face detection
