Hikvision DS-2CD1047G3-LIU

Name: Hikvision DS-2CD1047G3-LIU
Brand: Hikvision
SKU: 717364

Best offer

AED

349⁰⁰

AED

499⁰⁰

-30%

Key Features

Detect distance: 64m
Observe distance: 25m
Recognize distance: 12m
Noise reduction technology: 3D noise reduction
Lens viewing angle, vertical: 60°°
Lens viewing angle, diagonal: 143°°
Power consumption (Power over Ethernet (PoE)): 7.5W
Identify distance: 6m
Infrared (IR) cut-off filter: Yes
User access level: User
Digital watermark: Yes
Type: IP security camera
Active tampering alarm: Yes
Mirror: Yes
Supported graphics resolutions: 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 640 x 360, 640 x 480 (VGA)

Specifications

Features

Protection features

Waterproof

Number of sensors

Built-in microphone

✓

Audio formats supported

AAC-LC, G.711, G.722.1, G.726, MP2L2, PCM

Quality of Service (QoS) support

✗

Password protection

✓

Video motion detection

✓

Languages support

Polish

Number of languages

Connectivity technology

Wired

Product colour

White

Video streaming

✓

Digital watermark

✓

Type

IP security camera

Active tampering alarm

✓

Mirror

✓

Supported graphics resolutions

1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 640 x 360, 640 x 480 (VGA)

Detect distance

64 m

Packaging data

Package weight

800 g

Package height

150 mm

Package depth

141 mm

Package width

150 mm

Weight & dimensions

Weight

550 g

Height

67.90 mm

Width

69.80 mm

Length

172.90 mm

Management features

Web-based management

✓

Power

Power consumption (max)

6 W

DC output current

0.50 A

Power source type

PoE

DC output voltage

Power consumption (Power over Ethernet (PoE))

7.50 W

Other features

Noise reduction

✓

Ergonomics

Angle of rotation

360 °

Storage

Built-in HDD

✗

Design

International Protection (IP) code

IP67

Housing material

Metal, Plastic

Placement supported

Outdoor

Mounting type

Ceiling/Wall

Form factor

Bullet

Built-in light

✓

Network

Client interoperability

Hik-Connect, iVMS-4200

Wi-Fi

✗

Bluetooth

✗

Supported network protocols

DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4, IPv6, NTP, QoS, RTCP, RTP, RTSP, SMTP, TCP/IP, UDP, UPnP

Ethernet interface type

Fast Ethernet

Ethernet LAN

✓

Live view

✓

Number of simultaneous live view channels

6 channels

User access level

User

Ports & interfaces

Ethernet LAN (RJ-45) ports

Operational conditions

Operating relative humidity (H-H)

0 - 95 %

Storage relative humidity (H-H)

0 - 95 %

Technical details

Sustainability compliance

✓

Compliance certificates

BIS, CB, CE, Electromagnetic Compatibility (EMC), Industry Canada (IC), Low Voltage Directive (LVD), RCM, REACH, RoHS, WEEE

Audio

Built-in speaker(s)

✗

Lens system

Lens mount interface

M12

Maximum aperture number

Iris

✓

Number of lenses

Fixed focal length

2.80 mm

Identify distance

6 m

Noise reduction technology

3D noise reduction

Recognize distance

12 m

Observe distance

25 m

Video

Video compression formats

H.264, H.265, M-JPEG

Frame rate

25 fps

Image quality adjustment

Brightness, Contrast, Saturation, Sharpness

Privacy masking

✓

Security

Privacy protection

✓

Audit log

✓

Heartbeat

✓

Password reset via email

✓

Digest authentication

✓

Camera

Day/night mode

✓

Back Light Compensation (BLC)

✓

Number of Privacy masking areas

Camera shutter speed

1/3 - 1/100000 s

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Region of Interest (ROI) encoding

✓

Total megapixels

4 MP

Number of cameras

Bit rate

32 Kbps - 8 Mbps

Signal-to-Noise Ratio (SNR)

52 dB

Sensor type

CMOS

Lens viewing angle, horizontal

115°

Progressive scan

✓

Wide Dynamic Range (WDR)

✓

Highlight Compensation (HLC)

✓

Lens viewing angle, diagonal

143°

Lens viewing angle, vertical

60°

Amplifier

Sample rates

8 - 16 kHz

Pan-tilt unit

Tilt angle range

0 - 90 °

Pan range

0 - 360 °

Image sensor

Maximum resolution

2560 x 1440 pixels

Dynamic range

120 dB

Minimum illumination

0 lx

Infrared (IR) cut-off filter

✓

Night vision

✓

LED type

IR/White

Night vision distance

30 m

Infra-red wavelength

850 nm

Product Details

Designed to meet the SMB users’ primary security needs and beyond, Hikvision’s Value Series Network Cameras provide reliable protection and smart functions at fairly reasonable prices. The cameras feature Hikvision’s ColorVu low-light-imaging technology and support Motion Detection 2.0 that automatically tells humans and vehicles from other moving objects.
