30W Industrial Hardened Gigabit PoE Injector - 12-48V 30W 2x RJ45 IEEE802.3af/at/bt 10/100/1000Mbps 30W per port

RQG 30W Industrial Hardened Gigabit PoE Injector - 12-48V 30W 2x RJ45 IEEE802.3af/at/bt 10/100/1000Mbps 30W per port

Name: RQG 30W Industrial Hardened Gigabit PoE Injector - 12-48V 30W 2x RJ45 IEEE802.3af/at/bt 10/100/1000Mbps 30W per port
Brand: RQG
SKU: 474135

Specifications

Product Details

How to Set up

Step1: Connect the Ethernet port of the injector to a LAN switch with a network cable.

Step2: Connect the PoE Out port to the PoE device.

Step 3: After the device is powered on, the PWR indicator will all be on. If not, check the power supply connection.

SPECIFICATION

PoE Standards: IEEE802.3af Power over Ethernet, IEEE802.3at Power over Ethernet, IEEE802.3bt Power over Ethernet, Power Sourcing Equipment (PSE)

Max. Power: 30W per port

Input Power: 12-48V DC (Terminal Block)

Processing Type: Forward, Half-duplex, Full-duplex

Power Pin Assignment: Mode B: 4/5(+), 7/8(-)

Cabling: 10/100/1000Base-T: Cat5 or above

Connector: 2x 10/100/1000Base-T RJ45

Max. Distance: Cat5 UTP up to 100m

Operating Temperature : -40°C to 75°C (-40°F to 167°F)

MTBF: >200,000hrs

Dimensions: 3.74*2.76*1.18 inches

Weight: 0.55 lbs

PACKAGE

1 x 30W Industrial Hardened Gigabit PoE Injector

1 x Wall Mount Bracket

1 x Manual
