Elenzk 10G-30W - 12~48VDC 30W 1 IEEE802.3 af/at 10/100/1000/2.5G/5G/10G

Overview:

The Elenzk EK-002-30W is a Hardened 2.5G High Power PoE Injector allows you to connect the IEEE 802.3 af/at PoE device such as camera and access point with a non PoE LAN switch within the distance of 100m.

Both the Ethernet port (to switch) and the PoE Out port (to PoE device) support 10/100/1000/2.5G Base-T and are compliant with IEEE 802.3ab. The PoE Out port is also compliant with IEEE 802.3 at.

EK-002-30W provides an integrated power solution with a wide range voltage of 12~48VDC for high availability applications.

Features:

-- 12~48VDC Power Input;

-- 1 RJ45 Ethernet Data Input Port + 1 RJ45 Power Over Ethernet Output Port(Data + Power);

-- Support IEEE802.3at Power over Ethernet (PoE+) Power Sourcing Equipment;

-- Support 10/100/1000/2.5G Base-TX;

-- Forward Filter Rate: 3,720,000pps (2.5Gbps)

-- Cabling: Cat6 or above

-- Maximum Distance: Cat6 UTP up to 100m

-- Power Pin Assignment: 4/5(+), 7/8(-);

-- Support DIN-Rail & Wall-Mount installation;

-- Extensive LED indicators for PoE diagnostics;

-- Environmentally Hardened -40°C to 80°C (-40°F to 176°F) operating temperature;

-- Dimensions (WxDxH): 95*70*30 mm (3.74*2.76*1.18 inches);

-- Weight: 0.25Kg (0.55Ib);

-- Casing: Aluminum Case;

-- Warranty: 5-Year Warranty.

Package:

1 * Elenzk-INJ302 30W PoE Injector

1 * POE injector User Manual

1 * L-Shaped Wall Mount bracket

Note:

Power Options► The Power Supply for POE injector is to be purchased separately.► The cable is to be Cat6 or above.
