PRODUCTS DETAILS:
AC input power:100~240V 50HZ
Suitable battery cells:
①NiMH battery:1-4cells
②NiCd battery:1-4cells
③LiFePO4 battery:1-5cells
④Li-Ion battery:1-4cells
⑤Pb-Acid(AGM,Calcium,GEL, MF,EFB,SLA, VRLA, WET, Gel) battery:6V and 12V
Suitable battery type:2-18V Pb-Acid(AGM, VRLA, SLA, Gel), Li-Ion, LiFePO4, NiMH, NiCd
Charging method:PreCharge -C.C main charge -special charge CV or CC -end charge
Suitable battery capacity:1Ah ~ 200Ah
Suitable battery voltage*1:2.0V ~ 16.0V (For 24V battery, can only provide test function, no charge)
Charge/discharge voltage set:2.0V ~ 18.0V
Charge current set:0.4A ~ 4.0A (60W Max.)
Discharge current set:0.2A~2.0A (8W Max.)
Temperature compensation:Auto compensation charge voltage according to environment temperature
Voltage test precision:+- 1.0%
Current test precision:+- 2.5%
Capacity test precision:+- 2.5%
Abnormal protection:Shorted, reversed, OVP, OCP, OLP, OTP
Size and weight:6.30*3.46*1.38 inches, 1.4 pounds
Safety standard:CE,EN62368, EN61000,FCC,ROHS
