Hikvision DS-2CD2T42WD-I8

Name: Hikvision DS-2CD2T42WD-I8
Brand: Hikvision
SKU: 357475
Availability: InStock

Best offer

AED

399⁰⁰

Key Features

Infrared (IR) cut-off filter: Yes
Type: IP security camera
Active tampering alarm: Yes
Flip & mirror: Yes
Motion sensor: Yes
Supported graphics resolutions: 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2688 x 1520
DC output voltage: 12
Built-in HDD: No
Form factor: Box
Cabling technology: 10/100/1000Base-T(X)
Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Ethernet LAN: Yes
Remote viewing: Yes
Lens mount interface: M12
Maximum aperture number: 2

Specifications

Features

Weatherproof

✓

Card reader integrated

✗

Quality of Service (QoS) support

✓

Password protection type

User

Video motion detection

✓

Security algorithms

802.1x RADIUS

Connectivity technology

Wired, Wireless

Product colour

White

Type

IP security camera

Active tampering alarm

✓

Flip & mirror

✓

Motion sensor

✓

Supported graphics resolutions

1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2688 x 1520

Weight & dimensions

Weight

1200 g

Height

85.10 mm

Depth

299.70 mm

Width

86.50 mm

Diameter

105 mm

Management features

Web-based management

✓

Power

Power consumption (max)

10.50 W

Power over Ethernet (PoE)

✓

Power source type

PoE

DC output voltage

Other features

Noise reduction

✓

Storage

Built-in HDD

✗

Design

International Protection (IP) code

IP67

Housing material

Metal, Plastic

Placement supported

Outdoor

Mounting type

Ceiling/Wall, Wall

Form factor

Box

Network

Wi-Fi

✗

Networking standards

IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u

Supported network protocols

802.1X, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv6, NTP, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, TCP/IP, UDP, UPnP

Cabling technology

10/100/1000Base-T(X)

Ethernet interface type

Fast Ethernet, Gigabit Ethernet

Ethernet LAN

✓

Ports & interfaces

Interface

RJ-45

Ethernet LAN (RJ-45) ports

Operational conditions

Operating relative humidity (H-H)

0 - 95 %

Technical details

Remote viewing

✓

Audio

Automatic gain control

✓

Lens system

Lens mount interface

M12

Maximum aperture number

Fixed focal length

4 mm

Video

Video compression formats

H.264, M-JPEG

Video formats supported

H.264, M-JPEG

Frame rate

20 fps

Privacy masking

✓

Image quality adjustment

Brightness, Contrast, Saturation, Sharpness

Supported video modes

1080p, 720p

Security

IP address filtering

✓

Camera

Day/night mode

✓

Back Light Compensation (BLC)

✓

Field of view (FOV) angle

19.10 °

Camera shutter speed

1/3 - 1/10000 s

3D NR (Noise Reduction)

✓

Region of Interest (ROI) encoding

✓

Total megapixels

3 MP

Number of cameras

Sensor type

CMOS

Progressive scan

✓

Full HD

✓

Focus adjustment

1.4

PTZ control

✗

Wide Dynamic Range (WDR)

✓

Image sensor

Maximum resolution

2688 x 1520 pixels

Minimum illumination

0 lx

Infrared (IR) cut-off filter

✓

Night vision

✓

LED type

Night vision distance

80 m

Product Details

- 1/2.8” Progressive Scan CMOS - Up to 2 megapixel resolution - Full HD1080p real-time video - 120dB Wide Dynamic Range - 3D DNR - EXIR high performance LEDs - Up to 30/50/80 meters IR range - 12V DC±25% & PoE(802.3af Class3) - Support H.264+ - IP67

Files

Product Brochure

mmo_29916420_1467210787_3241_23605.pdf

PDF• 712.6 KB

User manual

mmo_29916420_1467210819_2777_16562.pdf

PDF• 4 MB
