Hikvision DS-2CC12D9T-IT3E

Name: Hikvision DS-2CC12D9T-IT3E
Brand: Hikvision
SKU: 357525
Availability: InStock

Best offer

AED

480⁰⁰

Key Features

Camera tilt control: Yes
Detect distance: 40m
Recognize distance: 80m
Camera pan control: Yes
Noise reduction technology: 3D noise reduction
Type: CCTV security camera
DC output voltage: 12
Number of effective pixels (H x V): 1920 x 1080pixels
Angle of rotation: 360°
Built-in HDD: No
Form factor: Dome
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Number of lenses: 1
Fixed focal length: 2.8mm

Specifications

Features

Number of sensors

Quality of Service (QoS) support

✓

Video motion detection

✓

Connectivity technology

Wired

Product colour

White

Type

CCTV security camera

Detect distance

40 m

Weight & dimensions

Weight

800 g

Height

93.20 mm

Depth

226 mm

Width

86.70 mm

Diameter

110 mm

Power

Power consumption (max)

4 W

Power over Ethernet (PoE)

✗

Power source type

DC output voltage

Performance

Number of effective pixels (H x V)

1920 x 1080 pixels

Camera pan control

✓

Other features

Noise reduction

✓

Ergonomics

Angle of rotation

360 °

Storage

Built-in HDD

✗

Design

International Protection (IP) code

IP67

Housing material

Metal, Plastic

Placement supported

Indoor/Outdoor, Outdoor

Mounting type

Ceiling/Wall

Form factor

Dome

Network

Wi-Fi

✗

Bluetooth

✗

Ethernet interface type

Fast Ethernet

Ethernet LAN

✓

Ports & interfaces

BNC output ports

Operational conditions

Operating relative humidity (H-H)

0 - 90 %

Lens system

Number of lenses

Fixed focal length

2.80 mm

Noise reduction technology

3D noise reduction

Recognize distance

80 m

Video

Frame rate

30 fps

Privacy masking

✓

Supported video modes

1080p

Camera

Day/night mode

✓

Gain control type

Auto

Back Light Compensation (BLC)

✓

Camera shutter speed

1/25 - 1/50000

Analog signal format system

PAL

Total megapixels

2 MP

Number of cameras

Sensor type

CMOS

Lens viewing angle, horizontal

103.5°

Progressive scan

✓

White balance

ATW

Wide Dynamic Range (WDR)

✓

Effective sensor resolution

2 pixels

Alarm input/output

✓

Highlight Compensation (HLC)

✓

Camera tilt control

✓

Pan-tilt unit

Tilt angle range

0 - 75 °

Pan range

0 - 360 °

Image sensor

Maximum resolution

1920 x 1080 pixels

Minimum illumination

0 lx

Night vision

✓

LED type

Night vision distance

40 m

Product Details

HD1080p/2MP CMOS Sensor/EXIR/40m IR/Outdoor EXIR Bullet/ICR/0.003 Lux/F1.2/12 VDC/built-in POC/Smart IR/3D DNR/OSD Menu/True WDR/IP67/2.8Lens

Files

User manual

mmo_36542198_1557402538_0059_8587.pdf

PDF• 3.5 MB

Product Brochure

mmo_36542198_1557402552_0171_18017.pdf

PDF• 793.2 KB
