Hikvision DS-2CD2766G2-IZS

Name: Hikvision DS-2CD2766G2-IZS
Brand: Hikvision
SKU: 895030

Best offer

AED

720⁰⁰

Key Features

Camera tilt control: Yes
Camera pan control: Yes
Noise reduction technology: 3D noise reduction
Lens viewing angle, vertical: 53°°
Lens viewing angle, diagonal: 117°°
Power consumption (Power over Ethernet (PoE)): 12.5W
Infrared (IR) cut-off filter: Yes
Alert notification type: E-mail
Type: IP security camera
Active tampering alarm: Yes
Mirror: Yes
Motion sensor: Yes
Sample rate: 48kHz
Supported graphics resolutions: 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520, 3200 x 1800, 3840 x 2160, 640 x 360, 640 x 480 (VGA)
Recognize distance (wide): 16m

Specifications

Features

Web browser

✓

Protection features

Dust resistant, Vandal proof, Water resistant

Voice codecs

AAC, G.711, G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM

Number of sensors

Card reader integrated

✓

Quality of Service (QoS) support

✓

Maximum memory card size

256 GB

Password protection

✓

Video motion detection

✓

Security algorithms

TLS

Languages support

Multi

Number of languages

Connectivity technology

Wired

Product colour

White

Video streaming

✓

Alert notification type

E-mail

Type

IP security camera

Active tampering alarm

✓

Mirror

✓

Motion sensor

✓

Sample rate

48 kHz

Supported graphics resolutions

1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520, 3200 x 1800, 3840 x 2160, 640 x 360, 640 x 480 (VGA)

Recognize distance (wide)

16 m

Recognize distance (tele)

42 m

Packaging data

Package weight

1730 g

Package height

173 mm

Package depth

174 mm

Package width

244 mm

Weight & dimensions

Weight

1110 g

Diameter

153 mm

Length

133.20 mm

Management features

Behavior analysis

Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection

Software reset

✓

Power

Power consumption (max)

10.50 W

DC output current

0.88 A

Power source type

PoE

DC output voltage

Power consumption (Power over Ethernet (PoE))

12.50 W

Performance

Camera pan control

✓

Other features

Noise reduction

✓

Ergonomics

Angle of rotation

355 °

Storage

Compatible memory cards

MicroSD (TransFlash), MicroSDHC, MicroSDXC, SDHC, SDXC

Built-in HDD

✗

Design

International Protection (IP) code

IP66

IK code

IK10

Housing material

Metal

Placement supported

Indoor/Outdoor, Outdoor

Reset button

✓

Mounting type

Ceiling/Wall

Form factor

Dome

Packaging content

Manual

✓

Network

Wi-Fi

✗

Bluetooth

✗

Networking standards

IEEE 802.3af

Supported network protocols

802.1X, ARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTP, RTSP, SMTP, SNMP, SSL/TLS, TCP/IP, UDP, UPnP

Ethernet interface type

Fast Ethernet

Ethernet LAN

✓

Ports & interfaces

Ethernet LAN (RJ-45) ports

Terminal block port

✓

Operational conditions

Operating relative humidity (H-H)

0 - 95 %

Storage relative humidity (H-H)

0 - 95 %

Technical details

Certification

CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013), CE-EMC (EN 55032: 2015, CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013), CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013) CE-RoHS (2011/65/EU), EN 50130-4: 2011 +A1: 2014), EN 61000-3-2: 2014, EN 61000-3-3: 2013, FCC (47 CFR Part 15, KC (KN 32: 2015, KN 35: 2015) UL (UL 60950-1), LOA (IEC/EN 60950-1) CE-ROHS (2011/65/EU), RCM (AS/NZS CISPR 32: 2015), REACH (Regulation (EC) No 1907/2006), Reach (Regulation (EC) No 1907/2006), Subpart B), WEEE (2012/19/EU)

Anti-flicker

✓

Compliance certificates

RoHS

Lens system

Maximum aperture number

1.40

Number of lenses

Detect distance (wide)

80 m

Detect distance (tele)

210 m

Observe distance (wide)

31 m

Observe distance (tele)

83 m

Identify distance (wide)

8 m

Identify distance (tele)

21 m

Noise reduction technology

3D noise reduction

Video

Video compression formats

H.264, H.265, M-JPEG

Frame rate

30 fps

Image quality adjustment

Brightness, Contrast, DNR, Saturation, Sharpness

Privacy masking

✓

Security

IP address filtering

✓

Audit log

✓

Heartbeat

✓

Password reset via email

✓

Pixel counter

✓

Flash log

✓

HTTPS encryption

✓

Camera

Day/night mode

✓

Gain control type

Auto

Back Light Compensation (BLC)

✓

Camera shutter speed

1/3 - 1/100000 s

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Region of Interest (ROI) encoding

✓

Total megapixels

6 MP

Number of cameras

Focal length range

2.8 - 12 mm

Bit rate

32 Kbps - 16 Mbps

Signal-to-Noise Ratio (SNR)

52 dB

Sensor type

CMOS

Lens viewing angle, horizontal

108°

Progressive scan

✓

Wide Dynamic Range (WDR)

✓

Auto focus

✓

Intelligent Video Surveillance (IVS) system features

Face detection, Scene change

Alarm input/output

✓

Highlight Compensation (HLC)

✓

Lens viewing angle, diagonal

117°

Lens viewing angle, vertical

53°

Camera tilt control

✓

Amplifier

Sample rates

8 - 48 kHz

Pan-tilt unit

Tilt angle range

0 - 75 °

Pan range

0 - 355 °

Image sensor

Maximum resolution

3200 x 1800 pixels

Minimum illumination

0 lx

Infrared (IR) cut-off filter

✓

Night vision

✓

LED type

Night vision distance

40 m

Infra-red wavelength

850 nm

Product Details

Empowered by deep learning algorithms, Hikvision AcuSense technology brings human and vehicle targets classification alarms to front- and back-end devices. The system focuses on human and vehicle targets, vastly improving alarm efficiency and effectiveness.

Deep Learning Algorithm

The Magic Behind It All As its name implies, Hikvision AcuSense Technology provides accurate sensing in security hardware. Empowered by deep learning algorithms, AcuSense technology distinguishes people and vehicles from other moving targets.

Human and Vehicle Intrusion

Spotlights the Events that Matter The most common concerns in perimeter protection are trespassing and vehicle break-ins. AcuSense helps you to focus on these events in two ways: alarm will only trigger when the preset intrusion type takes place, and related videos are sorted by categories for easier search.

Accurate Alarm for Human and Vehicle

You can focus on alarms triggered by humans and vehicles while false alarms triggered by small animals or other irrelevant objects are vastly reduced. Now you can enjoy this intelligent function with VCA or motion detection.

Visual and Auditory Warning

On-site response and deterrence methods using visual and customizable auditory warnings to add another layer of protection. Two-way audio function is now also available.
