Hikvision DS-2CD2783G2-IZS

Name: Hikvision DS-2CD2783G2-IZS
Brand: Hikvision
SKU: 357285

Best offer

AED

899⁰⁰

Key Features

Camera tilt control: Yes
Camera pan control: Yes
Noise reduction technology: 3D noise reduction
Lens viewing angle, vertical: 53°°
Lens viewing angle, diagonal: 117°°
Power consumption (Power over Ethernet (PoE)): 12.5W
Infrared (IR) cut-off filter: Yes
User access level: User
Digital watermark: Yes
Alert notification type: E-mail
Type: IP security camera
Active tampering alarm: Yes
Mirror: Yes
Fog proof: Yes
Motion sensor: Yes

Specifications

Features

Web browser

✓

Protection features

Dust resistant, Vandal proof, Water resistant

Voice codecs

AAC, G.711, G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM

Weatherproof

✓

Number of sensors

Audio formats supported

AAC-LC, G.711, G.722.1, G.726, MP2L2, MP3, PCM

Card reader integrated

✓

Quality of Service (QoS) support

✓

Maximum memory card size

256 GB

Password protection

✓

Video motion detection

✓

Security algorithms

EAP-LEAP, EAP-MD5, EAP-TLS, TLS

Languages support

Multi

Number of languages

Connectivity technology

Wired

Product colour

White

Video streaming

✓

Digital watermark

✓

Alert notification type

E-mail

Type

IP security camera

Active tampering alarm

✓

Mirror

✓

Fog proof

✓

Motion sensor

✓

Sample rate

48 kHz

Supported graphics resolutions

1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 2688 x 1520, 320 x 240, 3200 x 1800, 352 x 240, 352 x 288, 3840 x 2160, 640 x 360, 640 x 480 (VGA)

Recognize distance (wide)

16 m

Recognize distance (tele)

42 m

Packaging data

Package weight

1710 g

Package height

173 mm

Package depth

174 mm

Package width

244 mm

Weight & dimensions

Weight

830 g

Height

111.60 mm

Depth

153.30 mm

Width

153.30 mm

Diameter

153 mm

Length

133.20 mm

Management features

Web-based management

✓

Behavior analysis

Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection

Software reset

✓

Power

Power consumption (max)

10.50 W

Power over Ethernet (PoE)

✓

DC output current

0.88 A

Power source type

PoE

DC output voltage

Power consumption (Power over Ethernet (PoE))

12.50 W

Performance

Camera pan control

✓

Other features

I/O ports

1x line in, 1x line out

Noise reduction

✓

Ergonomics

Angle of rotation

355 °

Storage

Compatible memory cards

MicroSD (TransFlash), MicroSDHC, MicroSDXC, SDHC, SDXC

Built-in HDD

✗

Design

International Protection (IP) code

IP66

IK code

IK10

Housing material

Metal, Plastic

Placement supported

Indoor/Outdoor, Outdoor

Reset button

✓

Mounting type

Ceiling, Ceiling/Wall

Form factor

Dome

Packaging content

Manual

✓

Network

Client interoperability

Hik-Central, Hik-Connect, iVMS-4200

Wi-Fi

✗

Bluetooth

✗

Networking standards

IEEE 802.1x, IEEE 802.3af

Supported network protocols

802.1X, ARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, SSL/TLS, TCP/IP, UDP, UPnP, UPnP?, WebSocket, WebSockets

Streaming method

Multicast

Cabling technology

10/100Base-T(X)

Ethernet interface type

Fast Ethernet

Ethernet LAN

✓

Live view

✓

Number of simultaneous live view channels

6 channels

User access level

User

Ports & interfaces

Interface

RJ-45

Ethernet LAN (RJ-45) ports

Microphone in

✓

Alarm input channels

Alarm output channels

Terminal block port

✓

Composite video out

Operational conditions

Operating relative humidity (H-H)

0 - 95 %

Storage relative humidity (H-H)

0 - 95 %

Technical details

Certification

2016), B), BIS (IS 13252(1):2010+A1:2013+A2:2015), CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013), CB: IEC 62368-1: 2014+A11, CE-EMC (EN 55032: 2015, CE-EMC: EN 55032: 2015, CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013), CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013) CE-RoHS (2011/65/EU), CE-LVD: EN 62368-1: 2014/A11: 2017 CE-RoHS: 2011/65/EU, EN 50130-4: 2011 +A1: 2014, EN 50130-4: 2011 +A1: 2014), EN 61000-3-2: 2014, EN 61000-3-2:2019, EN 61000-3-3: 2013, EN 61000-3-3: 2013+A1:2019, FCC (47 CFR 15, FCC (47 CFR Part 15, FCC: 47 CFR Part 15, IC (ICES-003: 6, IC: ICES-003: Issue 7, KC (KN 32: 2015, KC: KN32: 2015, KN 35: 2015) UL (UL 60950-1), KN35: 2015 UL: UL 62368-1, LOA (IEC/EN 60950-1) CE-ROHS (2011/65/EU), RCM (AS/NZS CISPR 32: 2015), REACH ( (EC) No 1907/2006), REACH (Regulation (EC) No 1907/2006), Reach (Regulation (EC) No 1907/2006), Reach: Regulation (EC) No 1907/2006, Subpart B, Subpart B), WEEE (2012/19/EU), WEEE: 2012/19/EU

Anti-flicker

✓

Compliance certificates

RoHS

Audio

Automatic gain control

✓

Lens system

Minimum aperture number

1.20

Maximum aperture number

1.40

Number of lenses

Detect distance (wide)

80 m

Detect distance (tele)

210 m

Observe distance (wide)

31 m

Observe distance (tele)

83 m

Identify distance (wide)

8 m

Identify distance (tele)

21 m

Noise reduction technology

3D noise reduction

Video

Video compression formats

H.264, H.265, M-JPEG

Frame rate

30 fps

Image quality adjustment

Brightness, Contrast, DNR, Mirror, Saturation, Sharpness

Privacy masking

✓

Security

IP address filtering

✓

Privacy protection

✓

Audit log

✓

Heartbeat

✓

Password reset via email

✓

Pixel counter

✓

Flash log

✓

Automatic Network Replenishment (ANR)

✓

HTTPS encryption

✓

Focusing

Focus

Motorized

Camera

Day/night mode

✓

Gain control type

Auto

Back Light Compensation (BLC)

✓

Camera shutter speed

1/3 - 1/100000 s

3D NR (Noise Reduction)

✓

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Region of Interest (ROI) encoding

✓

Total megapixels

2 MP

Number of cameras

Focal length range

2.8 - 12 mm

Bit rate

32 Kbps - 16 Mbps

Analog signal format system

PAL

Signal-to-Noise Ratio (SNR)

52 dB

Sensor type

CIS, CMOS

Lens viewing angle, horizontal

108°

Progressive scan

✓

Full HD

✓

Wide Dynamic Range (WDR)

✓

Auto focus

✓

Intelligent Video Surveillance (IVS) system features

Crossing line, Face detection, Intrusion, Scene change

Alarm input/output

✓

Highlight Compensation (HLC)

✓

Lens viewing angle, diagonal

117°

Lens viewing angle, vertical

53°

Camera tilt control

✓

Amplifier

Sample rates

8 - 48 kHz

Pan-tilt unit

Tilt angle range

0 - 75 °

Pan range

0 - 355 °

Image sensor

Maximum resolution

1920 x 1080 pixels

Dynamic range

120 dB

Minimum illumination

0 lx

Infrared (IR) cut-off filter

✓

Night vision

✓

LED type

Night vision distance

40 m

Infra-red wavelength

850 nm

Product Details

Empowered by deep learning algorithms, Hikvision AcuSense technology brings human and vehicle targets classification alarms to front- and back-end devices. The system focuses on human and vehicle targets, vastly improving alarm efficiency and effectiveness.
