Dynatron K199

Name: Dynatron K199
Brand: Dynatron
SKU: 936973
Availability: InStock

Best offer

AED

313⁴¹

AED

313⁴²

<1%

Key Features

Minimum airflow (imperial): 5.355cfm
Fan dimensions (W x D x H): 80 x 80 x 15mm
Fan thickness: 15mm
Rotational speed (max): 5000RPM
Minimum air pressure: 2.083mmH2O
Maximum air pressure: 36.168mmH2O
Type: Cooler
Noise level (low speed): 20.71dB
Noise level (high speed): 51.7dB
Bearing technology: Double ball bearing
Maximum airflow: 14.719cfm
Power: 9.6W
Compatible processor series: Intel® Core™ i5, Intel® Core™ i7
Rotational speed (min): 1000RPM
Rack capacity: 1U

Specifications

Features

Compatible products

1220L, 1225, 1230, 1235, 1240, 1245, 1260L, 1270, 1275 & 1280 LGA1156: Intel Core i3 i3-530 & i3-540, Core i5 i5-650, Core i7 CPU, I7-870 & I7-860, LGA 1155: Intel 2nd Generation Core i7-2600, Xeon CPU 3400 Series, i5-2500 series & Sandy Bridge Xeon CPU 1220, i5-650, i5-660, i5-661 i5-670 & I5-750

Material

Copper

Fan diameter

80 mm

Connector(s)

4-Pin PWM

Suitable location

Processor

Supported processor sockets

LGA 1156 (Socket H)

Rack capacity

Product colour

Black

Rotational speed (max)

5000 RPM

Minimum air pressure

2.08 mmH2O

Maximum air pressure

36.17 mmH2O

Type

Cooler

Noise level (low speed)

20.71 dB

Noise level (high speed)

51.70 dB

Bearing technology

Double ball bearing

Maximum airflow

14.72 cfm

Weight & dimensions

Weight

355 g

Height

28.50 mm

Depth

81.50 mm

Width

85 mm

Fan thickness

15 mm

Fan dimensions (W x D x H)

80 x 15 x 80 mm

Power

Voltage

12 V

Power

9.60 W

Performance

Minimum airflow (imperial)

5.36 cfm

Processor

Compatible processor series

Intel® Core™ i5, Intel® Core™ i7

Circular saw

Rotational speed (min)

1000 RPM

Product Details

- Recommend for Intel Core i5 I5-750; Xeon CPU 3400 Series; Core i7 CPU I7-870 & I7-860; Socket LGA1156 - Active Cooler for 1U Server

Files

Product Brochure

mmo_20220140_1485166299_7927_19691.pdf

PDF• 54.2 KB
