AMAYYA Capacitor Meter - Digital LCD 200pF-20000uF

Feature: 1. Accurate Work: From 200pF to 20000uF, the capacitor meter has 9 kinds of measuring ranges as well as higher accuracy. 2. Broad Utility: Can be widely used to measure the capacitance of cables, switches , printed circuit board and so on. 3. Clear Display: Digital LCD screen enables easier data reading, which also simplifies the calibration and adjustment. 4. Simple to Use: 0?5 seconds sampling time together with simple operation will bring more convenience, very safe to use. 5. Easy Carrying: Comes with a light weight and a compact size, ideal for experiment, production line, maintenance, etc. How to Use: 1. Select the range switch according to the maximum expected value of the capacitance. 2. Zero Check Display: If the test range is 200pF, 2nF, 20nF, then the zero display should be checked before connecting the capacitor for testing. (But it must be after inserting the test lead or ruler) Rotate the adjustment knob on the front panel until the zero display is read. This zero adjustment function may be accurate to about ¡À25pF. 3. Connect crocodile clips to both ends of the capacitor. 4. Read the displayed value, and the read value will be read out directly according to&nbs
