Measuring voltage H/L, AC leakage current, current
Range:AC 0.00mA ~ 1000A
Peak load, Data storage: 99 groups
Line voltage: less than 60KV
Clamp size:Φ68mm
ETCR9200 H/L Voltage Clamp Current Meter applies to less than 60KV H/L and measure voltage leakage current and current. Range:0.00mA~1000A, jaw size Φ68mm, special alloy for current buckle, magnetic shield technology, strong anti-interference ability, ensure measurement accuracy and stability. The device has functions such as maximum retention, data retention and data storage (99 set). It can also be used as a test of high and low voltage ratios, that is, to measure high and low voltage currents of primary and secondary circuits, respectively, and can be calculated by manual calculation. High and low compression ratio.
The meter consists of a high voltage detector and 5 pieces of high voltage insulated rods. The insulation rod is light, with features such as resistance, high temperature resistance, impact resistance, bending resistance, high insulation, and detachability.
Function:AC current measurement of high voltage, AC/leakage current meter, online AC display
Power Source:DC6V (1.5V AAA x4) dry alkaline battery (not included)
Test method: CT clip, integrated method; connect the meter on the line to test, save the physical energy of the user.
Clamp Diameter:Φ68mm
Measurement Range:0.00mA~1000A (50Hz/60Hz Auto)
Resolution:0.01mA
Shift:0.00mA~1000A Automatic Transmission
Test Accuracy (23„ƒ±5„ƒ, ‰¤80%RH)
0.00mA~299mA: ±1%±3dgt
0.30A~49.9A:±1.5%±5DGT
50.0A~199.9A:±2%±5DGT
200A~600A:±3%±5DGT
601A~1000A: ±4%±5dgt
Display mode:4 digital LCD
LCD Dimensions:Tester:LCD:35mm*21.5mm
Meter Dimensions:Tester:218mm*135mm*60mm
Sampling speed: about 2 times/s
Data storage:99 groups, during storage, the symbol "MEM" gives an indication, the "Full" sign will flash to indicate that the memory has
