Hikvision DS-2CD2T63G2-4I

Name: Hikvision DS-2CD2T63G2-4I
Brand: Hikvision
SKU: 357527
Availability: InStock

Best offer

AED

399⁰⁰

Key Features

Noise reduction technology: 3D noise reduction
Lens viewing angle, vertical: 50°°
Lens viewing angle, diagonal: 97°°
Power consumption (Power over Ethernet (PoE)): 8.5W
Infrared (IR) cut-off filter: Yes
User access level: Administrator, Operator, User
Digital watermark: Yes
Fixed focus: Yes
Type: IP security camera
Active tampering alarm: Yes
Mirror: Yes
Supported graphics resolutions: 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 2944 x 1656, 3072 x 1728, 3072 x 2048, 320 x 240, 352 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA)
Behavior analysis: Intrusion detection, Line crossing detection
DC output voltage: 12
Angle of rotation: 360°

Specifications

Features

Web browser

✓

Protection features

Dust resistant, Water resistant

Number of sensors

Card reader integrated

✓

Quality of Service (QoS) support

✓

Maximum memory card size

128 GB

Password protection

✓

Languages support

Multi

Video motion detection

✓

Number of languages

Connectivity technology

Wired

Product colour

White

Video streaming

✓

Digital watermark

✓

Fixed focus

✓

Type

IP security camera

Active tampering alarm

✓

Mirror

✓

Supported graphics resolutions

1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 2944 x 1656, 3072 x 1728, 3072 x 2048, 320 x 240, 352 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA)

Packaging data

Package height

155 mm

Package depth

156 mm

Package width

386 mm

Weight & dimensions

Weight

1200 g

Diameter

105 mm

Length

299.70 mm

Management features

Behavior analysis

Intrusion detection, Line crossing detection

Power

Power consumption (max)

7.50 W

DC output current

0.60 A

Power source type

DC, PoE

DC output voltage

Power consumption (Power over Ethernet (PoE))

8.50 W

Other features

Noise reduction

✓

Ergonomics

Angle of rotation

360 °

Storage

Compatible memory cards

MicroSD (TransFlash), MicroSDHC, MicroSDXC

Built-in HDD

✗

Design

International Protection (IP) code

IP67

Housing material

Metal

Placement supported

Indoor/Outdoor

Reset button

✓

Mounting type

Ceiling/Wall

Form factor

Bullet

Network

Wi-Fi

✗

Bluetooth

✗

Networking standards

IEEE 802.1x, IEEE 802.3af

Supported network protocols

802.1X, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv6, NTP, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, SSL/TLS, TCP/IP, UDP, UPnP

Cabling technology

10/100Base-T(X)

Ethernet interface type

Fast Ethernet

Ethernet LAN

✓

User access level

Administrator, Operator, User

Ports & interfaces

Ethernet LAN (RJ-45) ports

Operational conditions

Operating relative humidity (H-H)

0 - 95 %

Technical details

Remote viewing

✓

Anti-flicker

✓

Lens system

Number of lenses

Minimum aperture number

1.20

Maximum aperture number

Noise reduction technology

3D noise reduction

Video

Video compression formats

H.264, H.265

Frame rate

30 fps

Privacy masking

✓

Image quality adjustment

Brightness, Contrast, Saturation, Sharpness

Security

IP address filtering

✓

Heartbeat

✓

Password reset via email

✓

Pixel counter

✓

HTTPS encryption

✓

Camera

Day/night mode

✓

Lens diameter

4 mm

Gain control type

Auto

Back Light Compensation (BLC)

✓

Camera shutter speed

1/3 - 1/100000 s

Region of Interest (ROI) encoding

✓

Bit rate

32 Kbps - 16 Mbps

Total megapixels

6 MP

Number of cameras

Sensor type

CMOS

Lens viewing angle, horizontal

78°

Progressive scan

✓

Wide Dynamic Range (WDR)

✓

Intelligent Video Surveillance (IVS) system features

Face detection

Highlight Compensation (HLC)

✓

Lens viewing angle, diagonal

97°

Lens viewing angle, vertical

50°

Pan-tilt unit

Tilt angle range

0 - 100 °

Pan range

0 - 360 °

Image sensor

Maximum resolution

3072 x 2048 pixels

Minimum illumination

0 lx

Infrared (IR) cut-off filter

✓

Night vision

✓

LED type

Night vision distance

50 m

Infra-red wavelength

850 nm

Product Details

With a perfect balance of performance and value, Hikvision Pro Series network cameras aim to provide just the right components, including intelligent features that are affordable and easy to use.

Hikvision AcuSense technology

Integrated with automatic triggering, Hikvision AcuSense Technology takes alarm accuracy and search efficiency to a whole new level.

Deep Learning Algorithm

The Magic Behind It All As its name implies, Hikvision AcuSense Technology provides accurate sensing in security hardware. Empowered by deep learning algorithms, AcuSense technology distinguishes people and vehicles from other moving targets.

Human and Vehicle Intrusion

Spotlights the Events that Matter The most common concerns in perimeter protection are trespassing and vehicle break-ins. AcuSense helps you to focus on these events in two ways: alarm will only trigger when the preset intrusion type takes place, and related videos are sorted by categories for easier search.

Accurate Alarm for Human and Vehicle

You can focus on alarms triggered by humans and vehicles while false alarms triggered by small animals or other irrelevant objects are vastly reduced. Now you can enjoy this intelligent function with VCA or motion detection.

Visual and Auditory Warning

On-site response and deterrence methods using visual and customizable auditory warnings to add another layer of protection. Two-way audio function is now also available.

Search Targets Quickly by Type

Video clips are sorted by human and vehicle categories, and object classification vastly improves search efficiency.

Files

Product Brochure

mmo_59938595_1634601156_4153_6903.pdf

PDF• 957 KB

User manual

mmo_59938595_1634601237_1042_6899.pdf

PDF• 52.5 MB

Quick Start Guide

mmo_59938595_1634601215_8018_6877.pdf

PDF• 2.6 MB

Videos

Turbo HD X security system, from responsive to active

MP4• 21.4 MB
