Hikvision DS-2CD1723G0-IZ

Name: Hikvision DS-2CD1723G0-IZ
Brand: Hikvision
SKU: 357507
Availability: InStock

Best offer

AED

552⁰⁰

Key Features

Camera tilt control: Yes
Camera pan control: Yes
Noise reduction technology: 3D noise reduction
Lens viewing angle, vertical: 52°°
Lens viewing angle, diagonal: 116°°
Power consumption (Power over Ethernet (PoE)): 12W
Infrared (IR) cut-off filter: Yes
User access level: User
Digital watermark: Yes
Type: IP security camera
Active tampering alarm: Yes
Mirror: Yes
Supported graphics resolutions: 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 320 x 240, 640 x 360, 640 x 480 (VGA)
Sample rate: 48kHz
Firmware version: V5.5.2

Specifications

Features

Voice codecs

G.711, G.722.1, G.726, MP2L2

Number of sensors

Card reader integrated

✓

Quality of Service (QoS) support

✓

Maximum memory card size

128 GB

Password protection

✓

Video motion detection

✓

Connectivity technology

Wired

Product colour

White

Video streaming

✓

Digital watermark

✓

Type

IP security camera

Active tampering alarm

✓

Mirror

✓

Supported graphics resolutions

1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 320 x 240, 640 x 360, 640 x 480 (VGA)

Sample rate

48 kHz

Packaging data

Package weight

1070 g

Package height

154 mm

Package depth

140 mm

Package width

140 mm

Weight & dimensions

Weight

830 g

Height

99.90 mm

Diameter

141 mm

Management features

Web-based management

✓

Firmware version

V5.5.2

Behavior analysis

Intrusion detection, Line crossing detection

Power

Power consumption (max)

10 W

DC output current

0.80 A

Power source type

PoE

DC output voltage

Power consumption (Power over Ethernet (PoE))

12 W

Performance

Camera pan control

✓

Other features

Noise reduction

✓

Ergonomics

Angle of rotation

360 °

Storage

Compatible memory cards

MicroSD (TransFlash), MicroSDHC, MicroSDXC

Built-in HDD

✗

Design

International Protection (IP) code

IP67

IK code

IK10

Housing material

Metal, Plastic

Placement supported

Indoor/Outdoor, Outdoor

Reset button

✓

Mounting type

Ceiling/Wall

Form factor

Dome

Network

Wi-Fi

✗

Bluetooth

✗

Networking standards

IEEE 802.1x, IEEE 802.3af

Supported network protocols

802.1X, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv6, NTP, QoS, RTCP, RTP, RTSP, SMTP, TCP/IP, UDP, UPnP

Live view

✓

Number of simultaneous live view channels

6 channels

Ethernet interface type

Fast Ethernet

Ethernet LAN

✓

User access level

User

Ports & interfaces

Ethernet LAN (RJ-45) ports

Operational conditions

Operating relative humidity (H-H)

0 - 95 %

Technical details

Anti-flicker

✓

Lens system

Number of lenses

Maximum aperture number

1.60

Noise reduction technology

3D noise reduction

Video

Video compression formats

H.264, H.265, M-JPEG

Frame rate

30 fps

Privacy masking

✓

Image quality adjustment

Brightness, Contrast, Saturation, Sharpness

Security

IP address filtering

✓

Privacy protection

✓

Heartbeat

✓

Automatic Network Replenishment (ANR)

✓

Camera

Day/night mode

✓

Gain control type

Auto

Back Light Compensation (BLC)

✓

Camera shutter speed

1/3 - 1/100000 s

Region of Interest (ROI) encoding

✓

Focal length range

2.8 - 12 mm

Bit rate

32 Kbps - 8 Mbps

Total megapixels

2 MP

Number of cameras

Sensor type

CMOS

Lens viewing angle, horizontal

98 - 34°

Progressive scan

✓

Wide Dynamic Range (WDR)

✓

Auto focus

✓

Intelligent Video Surveillance (IVS) system features

Face detection

Alarm input/output

✓

Highlight Compensation (HLC)

✓

Digital Wide Dynamic Range (DWDR)

✓

Lens viewing angle, diagonal

116°

Lens viewing angle, vertical

52°

Camera tilt control

✓

Pan-tilt unit

Tilt angle range

0 - 70 °

Pan range

0 - 355 °

Image sensor

Maximum resolution

1920 x 1080 pixels

Minimum illumination

0 lx

Infrared (IR) cut-off filter

✓

Night vision

✓

LED type

Night vision distance

50 m

Infra-red wavelength

850 nm

Product Details

Files

Product Brochure

mmo_69597065_1554116136_3028_26377.pdf

PDF• 775.7 KB

Quick Start Guide

mmo_69597065_1696072418_6638_30481.pdf

PDF• 3.5 MB

User manual

mmo_69597065_1696072439_6868_5919.pdf

PDF• 4.7 MB
