Hikvision DS-2CD1753G0-IZ

Name: Hikvision DS-2CD1753G0-IZ
Brand: Hikvision
SKU: 357077
Availability: InStock

Best offer

AED

602⁰⁰

Key Features

Camera tilt control: Yes
Camera pan control: Yes
Noise reduction technology: 3D noise reduction
Lens viewing angle, vertical: 54°°
Lens viewing angle, diagonal: 123°°
Power consumption (Power over Ethernet (PoE)): 11.5W
Infrared (IR) cut-off filter: Yes
Digital watermark: Yes
Type: IP security camera
Mirror: Yes
Supported graphics resolutions: 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 320 x 240, 640 x 360, 640 x 480 (VGA)
DC output voltage: 12
Angle of rotation: 355°
Built-in HDD: No
Form factor: Dome

Specifications

Features

Number of sensors

Card reader integrated

✓

Quality of Service (QoS) support

✓

Maximum memory card size

128 GB

Password protection

✓

Video motion detection

✓

Connectivity technology

Wired

Product colour

White

Video streaming

✓

Digital watermark

✓

Type

IP security camera

Mirror

✓

Supported graphics resolutions

1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 320 x 240, 640 x 360, 640 x 480 (VGA)

Packaging data

Package weight

1200 g

Package height

154 mm

Package depth

140 mm

Package width

140 mm

Weight & dimensions

Weight

820 g

Height

99.90 mm

Diameter

141 mm

Management features

Web-based management

✓

Power

Power consumption (max)

10 W

DC output current

0.80 A

Power source type

DC, PoE

DC output voltage

Power consumption (Power over Ethernet (PoE))

11.50 W

Performance

Camera pan control

✓

Other features

Noise reduction

✓

Ergonomics

Angle of rotation

355 °

Storage

Compatible memory cards

MicroSD (TransFlash), MicroSDHC, MicroSDXC

Built-in HDD

✗

Design

International Protection (IP) code

IP67

IK code

IK10

Housing material

Metal

Placement supported

Outdoor

Reset button

✓

Mounting type

Ceiling/Wall

Form factor

Dome

Network

Wi-Fi

✗

Bluetooth

✗

Networking standards

IEEE 802.1x, IEEE 802.3af

Supported network protocols

802.1X, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, QoS, RTCP, RTP, RTSP, SMTP, SSL/TLS, TCP/IP, UDP, UPnP™

Ethernet interface type

Fast Ethernet

Ethernet LAN

✓

Ports & interfaces

Ethernet LAN (RJ-45) ports

Operational conditions

Operating relative humidity (H-H)

0 - 95 %

Storage relative humidity (H-H)

0 - 95 %

Technical details

Certification

2016), B), BIS (IS 13252(1):2010+A1:2013+A2:2015), CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, CE-EMC (EN 55032: 2015, CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 50130-4: 2011 +A1: 2014), EN 61000-3-2: 2014, EN 61000-3-3: 2013, FCC SDoC (47 CFR 15, IC VoC (ICES-003: 6, IEC 62368-1:2014), KC (KN 32: 2015, KN 35: 2015) UL (UL 60950-1), RCM (AS/NZS CISPR 32: 2015)

Anti-flicker

✓

Lens system

Number of lenses

Maximum aperture number

1.60

Noise reduction technology

3D noise reduction

Video

Video compression formats

H.264, H.265, M-JPEG

Frame rate

30 fps

Privacy masking

✓

Image quality adjustment

Brightness, Contrast, Saturation, Sharpness

Security

IP address filtering

✓

Heartbeat

✓

Camera

Day/night mode

✓

Gain control type

Auto

Back Light Compensation (BLC)

✓

Camera shutter speed

1/3 - 1/100000 s

Region of Interest (ROI) encoding

✓

Focal length range

2.8-12 mm

Bit rate

32 Kbps - 8 Mbps

Total megapixels

4 MP

Number of cameras

Sensor type

CMOS

Lens viewing angle, horizontal

102°

Progressive scan

✓

Wide Dynamic Range (WDR)

✓

Auto focus

✓

Lens viewing angle, diagonal

123°

Lens viewing angle, vertical

54°

Camera tilt control

✓

Pan-tilt unit

Tilt angle range

0 - 70 °

Pan range

0 - 355 °

Image sensor

Maximum resolution

2560 x 1440 pixels

Minimum illumination

0 lx

Infrared (IR) cut-off filter

✓

Night vision

✓

LED type

Night vision distance

30 m

Infra-red wavelength

850 nm

Product Details

Files

Product Brochure

mmo_93023180_1631261416_818_17634.pdf

PDF• 1.4 MB

User manual

mmo_93023180_1631261431_3124_48635.pdf

PDF• 4.7 MB

Quick Start Guide

mmo_93023180_1631261449_0167_93.pdf

PDF• 2.6 MB
