Hikvision DS-2CD2046G2-IU

Name: Hikvision DS-2CD2046G2-IU
Brand: Hikvision
SKU: 357399
Availability: InStock

Best offer

AED

369⁰⁰

Key Features

Camera tilt control: Yes
Camera pan control: Yes
Noise reduction technology: 3D noise reduction
Lens viewing angle, vertical: 55°°
Lens viewing angle, diagonal: 123°°
Power consumption (Power over Ethernet (PoE)): 6.5W
Infrared (IR) cut-off filter: Yes
Alert notification type: E-mail
Type: IP security camera
Active tampering alarm: Yes
Mirror: Yes
Motion sensor: Yes
Sample rate: 48kHz
Supported graphics resolutions: 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2304 x 1296, 2592 x 1944, 2688 x 1520, 2944 x 1656, 320 x 240, 360 x 240, 640 x 360, 640 x 480 (VGA)
Recognize distance (wide): 12m

Specifications

Features

Web browser

✓

Protection features

Dust resistant, Vandal proof, Water resistant

Voice codecs

AAC, G.711, G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM

Number of sensors

Built-in microphone

✓

Audio formats supported

G.711 A-law, G.711 μ-law, G.722.1, G.726, MP2L2, MP3, PCM

Card reader integrated

✓

Quality of Service (QoS) support

✓

Maximum memory card size

256 GB

Password protection

✓

Video motion detection

✓

Security algorithms

TLS

Languages support

Traditional Chinese, Danish, German, Dutch, Finnish, HRV, Hungarian, Italian, Japanese, Korean, LAT, Multi, Polish, Portuguese, RON, Russian, SER, Slovak, Slovenian, SPA, Swedish, Thai, Turkish, Vietnamese

Number of languages

Connectivity technology

Wired

Product colour

White

Video streaming

✓

Alert notification type

E-mail

Type

IP security camera

Active tampering alarm

✓

Mirror

✓

Motion sensor

✓

Sample rate

48 kHz

Supported graphics resolutions

1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2304 x 1296, 2592 x 1944, 2688 x 1520, 2944 x 1656, 320 x 240, 360 x 240, 640 x 360, 640 x 480 (VGA)

Recognize distance (wide)

12 m

Packaging data

Package weight

1620 g

Package height

150 mm

Package depth

170 mm

Package width

150 mm

Weight & dimensions

Weight

585 g

Height

92 mm

Diameter

138 mm

Length

287.60 mm

Management features

Web-based management

✓

Behavior analysis

Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection

Power

Power consumption (max)

5.80 W

DC output current

0.45 A

Power source type

PoE

DC output voltage

Power consumption (Power over Ethernet (PoE))

6.50 W

Performance

Camera pan control

✓

Other features

Noise reduction

✓

Ergonomics

Angle of rotation

360 °

Storage

Compatible memory cards

MicroSD (TransFlash), MicroSDHC, MicroSDXC, SDHC, SDXC

Built-in HDD

✗

Design

International Protection (IP) code

IP67

IK code

IK10

Housing material

Aluminium, Metal

Placement supported

Indoor/Outdoor, Outdoor

Reset button

✓

Mounting type

Ceiling/Wall

Form factor

Bullet

Packaging content

Manual

✓

Network

Wi-Fi

✗

Bluetooth

✗

Networking standards

IEEE 802.1x, IEEE 802.3af

Supported network protocols

802.1X, ARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTP, RTSP, SMTP, SNMP, SSL/TLS, TCP/IP, UDP, UPnP

Ethernet interface type

Fast Ethernet

Ethernet LAN

✓

Ports & interfaces

Ethernet LAN (RJ-45) ports

Operational conditions

Operating relative humidity (H-H)

0 - 95 %

Storage relative humidity (H-H)

0 - 95 %

Technical details

Certification

2016), B), BIS (IS 13252(Part 1):2010+A1:2013+A2:2015), BIS (IS 13252(Part 1): 2010+A1: 2013+A2: 2015), CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013), CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013), CE-EMC (EN 55032: 2015, CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013), CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013), EMC FCC (47 CFR Part 15, EN 61000-3-3: 2013, EN 50130-4: 2011 + A1: 2014), EN 50130-4: 2011 +A1: 2014), EN 61000-3-2: 2014, EN 61000-3-3: 2013, FCC (47 CFR 15, FCC (47 CFR 15, FCC (47 CFR Part 15, IC (ICES-003: Issue 6, IC (ICES-003: 6, IC (ICES-003: Issue 6, IEC 62368-1: 2014 ), KC (KN 32: 2015, KN 35: 2015), KN 35: 2015) Safety UL (UL 60950-1), KN 35: 2015) UL (UL 60950-1), KN 35: 2015) UL (UL 60950-1), LOA (IEC/EN 60950-1) CE-RoHS (2011/65/EU), LOA (IEC/EN 60950-1) Environment CE-RoHS (2011/65/EU), LOA (IEC/EN 60950-1) CE-RoHS (2011/65/EU), RCM (AS/NZS CISPR 32: 2015), Reach ( (EC) No 1907/2006), Reach ((EC) No 1907/2006), Reach (Regulation (EC) No 1907/2006), Subpart B), WEEE (2012/19/EU)

Anti-flicker

✓

Compliance certificates

RoHS

Audio

Built-in speaker(s)

✓

Lens system

Maximum aperture number

1.40

Number of lenses

Fixed focal length

2.80 mm

Detect distance (wide)

60 m

Observe distance (wide)

23.80 m

Identify distance (wide)

6 m

Noise reduction technology

3D noise reduction

Video

Video compression formats

H.264, H.265, M-JPEG

Frame rate

30 fps

Image quality adjustment

Brightness, Contrast, DNR, Saturation, Sharpness

Privacy masking

✓

Security

IP address filtering

✓

Heartbeat

✓

HTTPS encryption

✓

Camera

Day/night mode

✓

Gain control type

Auto

Back Light Compensation (BLC)

✓

Camera shutter speed

1/3 - 1/100000 s

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Region of Interest (ROI) encoding

✓

Total megapixels

4 MP

Number of cameras

Bit rate

32 Kbps - 8 Mbps

Signal-to-Noise Ratio (SNR)

52 dB

Sensor type

CMOS

Lens viewing angle, horizontal

103°

Progressive scan

✓

Wide Dynamic Range (WDR)

✓

Intelligent Video Surveillance (IVS) system features

Crossing line, Face detection, Intrusion, Scene change

Alarm input/output

✓

Highlight Compensation (HLC)

✓

Lens viewing angle, diagonal

123°

Lens viewing angle, vertical

55°

Camera tilt control

✓

Amplifier

Sample rates

8 - 48 kHz

Pan-tilt unit

Tilt angle range

0 - 75 °

Pan range

0 - 360 °

Image sensor

Maximum resolution

2592 x 1944 pixels

Minimum illumination

0 lx

Infrared (IR) cut-off filter

✓

Night vision

✓

LED type

Night vision distance

30 m

Infra-red wavelength

850 nm

Product Details

Empowered by deep learning algorithms, Hikvision AcuSense technology brings human or vehicle target classification alarms to front- and back-end devices. The system can greatly reduce false alarms generated by targets other than humans or vehicles, vastly improving alarm efficiency and effectiveness.

Deep learning algorithm

The magic behind it all As its name implies, Hikvision AcuSense Technology provides accurate sensing in security hardware. Empowered by deep learning algorithms, AcuSense technology distinguishes people and vehicles from other moving targets.

Human and vehicle intrusion

Spotlights the events that matter The most common concerns in perimeter protection are trespassing and vehicle break-ins. AcuSense helps you to focus on these events in two ways: alarm will only trigger when the preset intrusion type takes place, and related videos are sorted by categories for easier search.

Accurate alarm for human and vehicle

You can focus on alarms triggered by humans and vehicles while false alarms triggered by small animals or other irrelevant objects are vastly reduced. Now you can enjoy this intelligent function with VCA or motion detection.

Visual and auditory warning

On-site response and deterrence methods using visual and customizable auditory warnings to add another layer of protection. Two-way audio function is now also available.

Search targets quickly by type

Video clips are sorted by human and vehicle categories, and object classification vastly improves search efficiency.

Files

Product Brochure

mmo_113432446_1755676638_0967_157853.pdf

PDF• 1 MB

Quick Start Guide

mmo_113432446_1755676639_1915_157853.pdf

PDF• 21.6 MB

User manual

mmo_113432446_1755676639_2211_157853.pdf

PDF• 52.5 MB

Images

Videos

AcuSense products for Warehouses

MP4• 5.3 MB

AcuSense Products for Monitoring Centers

MP4• 4.1 MB

AcuSense Products for Restricted Areas

MP4• 7.5 MB

AcuSense Products for Residences

MP4• 8 MB

YouTube
