Hikvision DS-2CD2532F-IWS

Name: Hikvision DS-2CD2532F-IWS
Brand: Hikvision
SKU: 357286
Availability: InStock

Best offer

AED

855⁰⁰

AED

2 250⁰⁰

-62%

Key Features

Infrared (IR) cut-off filter: Yes
Type: IP security camera
Active tampering alarm: Yes
Flip & mirror: Yes
Motion sensor: Yes
Supported graphics resolutions: 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Frequency band: 2.4 - 2.4835 GHz, 2.4 GHzGHz
DC output voltage: +12V, 12
Angle of rotation: 360°
Built-in HDD: No
Form factor: Dome
Cabling technology: 10/100Base-T(X)
Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes

Specifications

Features

Protection features

Vandal proof

Voice codecs

G.711, G.722.1, G.726

Weatherproof

✓

Built-in microphone

✓

Audio formats supported

G.711, G.726

Card reader integrated

✓

Quality of Service (QoS) support

✓

Maximum memory card size

64GB, 128GB

Password protection type

User

Video motion detection

✓

Security algorithms

128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS

Connectivity technology

Wired

Product colour

White

Type

IP security camera

Active tampering alarm

✓

Flip & mirror

✓

Motion sensor

✓

Supported graphics resolutions

1280 x 720 (HD 720), 1920 x 1080 (HD 1080)

Frequency band

2.4 - 2.4835 GHz, 2.4 GHz

Weight & dimensions

Weight

350g, 600g

Height

52.80mm, 56.50mm

Depth

96.70mm, 97.50mm

Width

99.30mm, 99.90mm

Power

Power consumption (max)

5W, 9W

Power over Ethernet (PoE)

✓

Power source type

PoE

DC output voltage

+12V, 12

Other features

Noise reduction

✓

Ergonomics

Angle of rotation

360 °

Storage

Compatible memory cards

MicroSD (TransFlash), MicroSDHC, MicroSDXC

Built-in HDD

✗

Design

International Protection (IP) code

IP66, IP67

Placement supported

Indoor/Outdoor, Outdoor

Reset button

✓

Mounting type

Ceiling, Ceiling/Desk, Ceiling/Wall

Form factor

Dome

Network

Wi-Fi

✓

Networking standards

IEEE 802.3af

Supported network protocols

802.1X, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv6, NTP, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, TCP/IP, UDP, UPnP

Cabling technology

10/100Base-T(X)

Wi-Fi standards

802.11b, 802.11g, Wi-Fi 4 (802.11n)

Ethernet interface type

Fast Ethernet

Ethernet LAN

✓

Ports & interfaces

Interface

RJ-45

Ethernet LAN (RJ-45) ports

Operational conditions

Operating relative humidity (H-H)

0 - 95 %

Audio

Automatic gain control

✓

Lens system

Lens mount interface

M12

Maximum aperture number

Fixed focal length

2.80mm, 4mm, 6mm

Video

Video compression formats

H.264, M-JPEG

Video formats supported

H.264, M-JPEG

Frame rate

20fps, 30fps

Privacy masking

✓

Image quality adjustment

Brightness, Contrast, Saturation, Sharpness

Supported video modes

1080p, 720p

Security

IP address filtering

✓

Camera

Day/night mode

✓

Field of view (FOV) angle

79°, 106°

Camera shutter speed

1/3 - 1/10000 s, 1/30 - 1/100000 s

Total megapixels

3MP, 4MP

Number of cameras

Sensor type

CMOS

Progressive scan

✓

Full HD

✓

Focus adjustment

2.0

Wide Dynamic Range (WDR)

✓

Alarm input/output

✓

Shutter

Camera shutter type

Electronic

Pan-tilt unit

Tilt angle range

0 - 75 °

Image sensor

Maximum resolution

2048 x 1536, 2688 x 1520

Minimum illumination

0lx, 0.19lx

Infrared (IR) cut-off filter

✓

Night vision

✓

LED type

Night vision distance

10 m

Product Details

- 4MP (2688×1520) high resolution - Up to 10m IR visibility - Support 120dB wide dynamic range - PoE - ICR&3D DNR&BLC&ROI - IP66 rating - Vandal-proof housing

Files

Product Brochure

mmo_30408642_1470922369_6736_13234.pdf

PDF• 838 KB

User manual

mmo_30408642_1470922411_1494_26985.pdf

PDF• 4 MB
