Cisco SG350X-8PMD 8-Ports

Key Features

  • Switch layer: L2/L3
  • Physical stacking (units): 4
  • Basic switching RJ-45 Ethernet ports quantity: 8
  • 2.5G Ethernet (copper) ports quantity: 8
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • DHCP features: DHCP client, DHCP relay, DHCP server, DHCP snooping
  • Number of queues: 8
  • Number of static routes: 8000
  • Number of IP interfaces: 256
  • Static route: Yes
  • Number of multicast groups filtered: 4000
  • Gigabit Ethernet (copper) ports quantity: 6
  • Port mirroring: Yes
  • Power over Ethernet plus (PoE+) ports quantity: 8
  • IP routing: Yes
  • Offers
  • Price History
  • Specifications
  • Product Details
  • Review IconReviews

Specifications

Features

Country of origin
China
Mean time between failures (MTBF)
474265 h
Internal memory
512 MB
Processor frequency
800 MHz
Quality of Service (QoS) support
✓
Security algorithms
802.1x RADIUS, HTTPS, MD5, SNMP, SSH, SSL/TLS
Rack mounting
✓
Noise level
42.90 dB
Stackable
✓
Virtual LAN features
IP subnet–based VLAN, MAC address-based VLAN, Multicast VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, VLAN mapping, Voice VLAN
Product colour
Black
Packet buffer memory
1.50 MB
Queue scheduling algorithms
SP, WRR+SP, Weighted Round Robin (WRR)
SFP+ module slots quantity
2
Telnet
✓
Access Control List (ACL)
✓
Access Control List (ACL) rules
2000
Switching capacity
80 Gbit/s
MAC address table
32000 entries
Authentication type
IEEE 802.1x, RADIUS
Jumbo frames support
✓
Forwarding rate
29.76 Mpps
Multicast support
✓
Static route
✓
Switch layer
L2/L3

Packaging data

Package weight
7940 g
Package height
108 mm
Package depth
476.50 mm
Package width
476 mm

Weight & dimensions

Weight
2740 g
Height
44 mm
Depth
440 mm
Width
252.50 mm

Management features

Web-based management
✓
Firmware upgradeable
✓
System event log
✓
ARP inspection
✓
Number of multicast groups filtered
4000

Power

Power plug type
Type C
AC input voltage
100 - 240 V
AC input frequency
50 Hz
Input current
0.7 A
Power consumption (max)
50.30 W
Power over Ethernet (PoE)
✓
Power over Ethernet (PoE) power per port
60 W
Total Power over Ethernet (PoE) budget
240 W
Number of power supply units
1

Performance

sFlow
✓
Physical stacking (units)
4

Wireless LAN features

IGMP snooping
✓

Design

Stacking
✓
Reset button
✓
LED indicators
Yes
Form factor
1U

Computer system

Built-in processor
✓

Packaging content

Packaging content
Rubber feet
Quick start guide
✓
Cables included
AC, Serial
Power supply included
✓
Rack mount kit
✓

Network

Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Management protocols
2, 3, SNMP v1
VLAN support
✓
Number of VLANs
4094
Spanning tree protocol
✓
Head-of-line (HOL) blocking
✓
Rate limiting
✓
Active link detection
✓
Cable length detection
✓
Flow control support
✓
Copper ethernet cabling technology
1000BASE-T, 100BASE-T, 10BASE-T
10G support
✓
Link aggregation
✓
Jumbo frames
9000
Port mirroring
✓

Ports & interfaces

Power over Ethernet (PoE) ports quantity
24
Fiber optic connector
SFP
Cable types supported
Cat5, Cat6, Cat7
Console port
RJ-45
USB 2.0 ports quantity
1
Combo SFP ports quantity
2
Power over Ethernet plus (PoE+) ports quantity
8
Gigabit Ethernet (copper) ports quantity
6
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
2.5G Ethernet (copper) ports quantity
8
Basic switching RJ-45 Ethernet ports quantity
8

Operational conditions

Operating temperature (T-T)
0 - 50 °C
Operating relative humidity (H-H)
10 - 90 %
Storage relative humidity (H-H)
10 - 90 %
Heat dissipation
1065.90 BTU/h

Technical details

Certification
CE, CSA, CSA (CSA 22.2), FCC, FCC Part 15 (CFR 47) Class A, UL, UL (UL 60950)
Switch type
Managed

Memory

Flash memory
256 MB

Protocols

IPv4 & IPv6 features
Dual stack IPv4/IPv6, IPv6 First Hop Security​ (FHS), IPv6 Telnet, IPv6 ping
GARP VLAN Registration Protocol (GVRP)
✓
Intra-Site Automatic Tunnel Addressing Protocol (ISATAP)
✓

Data transmission

Number of IP interfaces
256
Number of static routes
8000
Number of queues
8

Security

MAC address filtering
✓
IP Source Guard (IPSG)
✓
SSH/SSL support
✓
Broadcast storm control
✓
Static port security
✓
Loop protection
✓
BPDU filtering/protection
✓
DoS attack prevention
✓
IP-MAC-Port binding
✓
Authentication
Guest VLAN, Port-based authentication, Web-based authentication
Root protection
✓
DHCP features
DHCP client, DHCP relay, DHCP server, DHCP snooping

Ethernet LAN features

IP routing
✓

Logistics data

Harmonized System (HS) code
85176990

Product Details

The Cisco® 350X Series Stackable Managed Switches are a new line of stackable managed Ethernet switches that provide the rich capabilities you need to support a more demanding network environment at a very affordable price. The SG350X models provide 24 or 48 ports of Gigabit and Multigigabit Ethernet connectivity with 10 Gigabit uplinks. The Cisco 350XG models provide 12, 24, or 48 ports of all 10 Gigabit Ethernet, providing a solid foundation for your current business applications as well as those you are planning for the future. In addition, these switches are easy to deploy and manage without a large IT staff. The SG350X platforms are Cisco’s most cost-effective platforms with 10 Gigabit Ethernet and stacking. Cisco 350X Series switches are designed to protect your technology investment as your business grows. Unlike switches that claim to be stackable but have elements that are administered and troubleshot separately, the Cisco 350X Series provides true stacking capability, allowing you to configure, manage, and troubleshoot multiple physical switches as a single device and more easily expand your network. A true stack delivers a unified data and control plane, in addition to management plane, providing flexibility, scalability, and ease of use because the stack of units operates as a single entity constituting all the ports of the stack members. The switches also protect your technology investment with an enhanced warranty, dedicated technical support, and the ability to upgrade equipment in the future. Overall, the Cisco 350X Series provides the ideal technology foundation for a growing business.

Files

Product Brochure

mmo_41702880_1543843099_1924_21053.pdf

PDF• 750.4 KB

User manual

mmo_41702880_1543843123_365_21279.pdf

PDF• 911.2 KB

Videos

Portfolio Overview Video

MP4• 8.8 MB
