Cisco MS225-24P 24-ports

Best offer
AED
10 73037

This price may no longer be valid

Key Features

  • Switch layer: L2
  • Basic switching RJ-45 Ethernet ports quantity: 24
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • DHCP features: DHCP client, DHCP server
  • Number of queues: 8
  • Number of multicast groups filtered: 256
  • Gigabit Ethernet (copper) ports quantity: 26
  • Port mirroring: Yes
  • SFP+ module slots quantity: 4
  • Switching capacity: 128Gbit/s
  • MAC address table: 16000entries
  • Access Control List (ACL): Yes
  • Multicast support: Yes
  • Power source: DC/PoE
  • IGMP snooping: Yes
  • Offers
  • Price History
  • Specifications
  • Product Details
  • Review IconReviews

Specifications

Features

Mean time between failures (MTBF)
391648 h
Internal memory
128 MB
MIB support
Y
Quality of Service (QoS) support
✓
Security algorithms
802.1x RADIUS, SSL/TLS
Rack mounting
✓
Stackable
✓
Product colour
Grey
Packet buffer memory
4.10 MB
SFP+ module slots quantity
4
Switching capacity
128 Gbit/s
MAC address table
16000 entries
Access Control List (ACL)
✓
Multicast support
✓
Switch layer
L2

Weight & dimensions

Weight
3710 g
Height
43.80 mm
Depth
201 mm
Width
484.60 mm

Management features

Web-based management
✓
Firmware upgradeable
✓
System event log
✓
Number of multicast groups filtered
256

Power

AC input voltage
100 - 240 V
Power consumption (typical)
21 W
AC input frequency
47/63 Hz
Power consumption (max)
882 W
Power over Ethernet (PoE)
✓
Power source
DC/PoE

Wireless LAN features

IGMP snooping
✓

Design

LED indicators
Yes
Form factor
1U

Packaging content

Quick start guide
✓
Cables included
AC
Power supply included
✓

Network

Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Management protocols
SNMP v1, SNMP v2, SNMP v3
VLAN support
✓
Number of VLANs
4095
Auto MDI/MDI-X
✓
Spanning tree protocol
✓
Head-of-line (HOL) blocking
✓
Rate limiting
✓
10G support
✗
Link aggregation
✓
Flow control support
✓
Port mirroring
✓

Ports & interfaces

Combo SFP ports quantity
2
Gigabit Ethernet (copper) ports quantity
26
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity
24

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
5 - 95 %
Storage relative humidity (H-H)
10 - 90 %
Heat dissipation
64.50 BTU/h

Technical details

Certification
CE, CSA (CSA 22.2), FCC, UL (UL 60950)
Switch type
Managed

Memory

Flash memory
32 MB

Data transmission

Number of queues
8

Security

MAC address filtering
✓
SSH/SSL support
✓
Broadcast storm control
✓
DHCP features
DHCP client, DHCP server

Logistics data

Harmonized System (HS) code
85176990

Product Details

Cisco 220 Series Smart Switches, part of the Cisco Small Business line of network solutions, are simple, secure and smart switches equipped with enhanced security, management, and performance. Models include 24 or 48 ports of Fast Ethernet, with two Gigabit Ethernet uplinks, and 26 or 50 ports of Gigabit Ethernet connectivity, all with Power over Ethernet (PoE) options. This series of switches provides enhanced capabilities like access control list, command line interface, and PoE+. Offered with limited lifetime warranty, these switches deliver the ideal combination of features, performance, and ease of use to build a fast, reliable and secure business network, at a lower cost than managed switches. - Layer 2 - 24 x 10/100/1000 Ports + 2 x combo Gigabit SFP - Desktop or rack-mountable - 1U - Switching capacity: 38.69 Mpps ¦ Forwarding performance (64-byte packet size): 52 Gbps

Files

Product Brochure

mmo_22791279_1487084026_2931_5814.pdf

PDF• 582.2 KB

Quick Start Guide

mmo_22791279_1487084206_7239_4062.pdf

PDF• 696.6 KB

Cisco 220 Series Smart Plus Switches Administration Guide Release 1.1.0.x

mmo_22791279_1487084257_2312_29956.pdf

PDF• 2.7 MB
