QSFPTEK QAP-630E

Item: QAP-630E Weight: 420(g) Mounting method: Ceiling Dimensions (excluding accessories)(mm): 186×186×36(mm) Ethernet port 1×2.5G WAN Port 1 GE WAN port (POE supported) Local power supply: POE input or 12V DC PoE power supply: 802.3at Antenna type: Built-in omnidirectional Antenna gain: 2.4G: 3dBi 5G: 3dBi Operatingfrequencybands: 802.11a/n/ac: 5.725GHz-5.850GHz ; 5.15-5.35GHz 802.11 b/g/n/ac: 2.4GHz-2.483GHz Wi-Fidatarate: 2.4G: 2*2 11ax 576Mbps 5G: 2*2 11ax 2400Mbps Maximum total transmitting power (The actual transmission power is subject to relevant regulations.): 2.4 GHz: 27 dBm (combined power) 5 GHz: 23 dBm (combined power) Modulation technology: OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps DSSS:DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps MIMO-OFDM(11n):MCS 0-15 MIMO-OFDM(11ac):MCS 0-9 MIMO-OFDM(11ax):MCS 0-11 Modulation mode: 11b: DSS:CCK@5.5/11Mbps, DQPSK@2Mbps, DBPSK@1Mbps 11a/g: OFDM:64QAM@48/54Mbps, 16QAM@24Mbps, QPSK@12/18Mbps, BPSK@6/9Mbps 11n: MIMO-OFDM:BPSK, QPSK, 16QAM, 64QAM 11ac: MIMO-OFDM:BPSK, QPSK, 16QAM, 64QAM, 256QAM 11ax: MIMO-OFDM:BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM Power adjustment: Automatic Reset: Supported Status LED: on / Blinking/ error Operating temperature/ Storage temperature: -10ºC~40ºC/-40ºC~70ºC Operating humidity / Storage humidity: 10%~95% (non-condensing) Protection class: IP41 Power consumption: <18W MTBF: >250000H
