Ubiquiti U6-Mesh

Name: Ubiquiti U6-Mesh
Brand: Ubiquiti
SKU: 134004
Availability: InStock

Best offer

AED

644⁴⁰

AED

649⁰⁰

<1%

Key Features

2.4 GHz: Yes
5 GHz: Yes
6 GHz: No
Maximum data transfer rate (2.4 GHz): 573.5Mbit/s
Maximum data transfer rate (5 GHz): 4800Mbit/s
Antenna direction type: Omni-directional
PoE adapter included: Yes
Antenna gain level (max): 8dBi
Maximum data transfer rate: 4800Mbit/s
Placement: Ceiling, Pole, Table, Wall
DC voltage range: 42.5 - 57 VV
Frequency band: 2.4 - 5 GHzGHz
Antenna type: Internal
Cabling technology: 10/100/1000Base-T(X)
MIMO type: Multi User MIMO

Specifications

Features

Recommended usage

Indoor/outdoor

Quality of Service (QoS) support

✓

Security algorithms

WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3

MIMO

✓

Product colour

White

Antenna gain level (max)

8 dBi

Maximum data transfer rate

4800 Mbit/s

Placement

Ceiling, Pole, Table, Wall

DC voltage range

42.5 - 57 V

Frequency band

2.4 - 5 GHz

Maximum data transfer rate (5 GHz)

4800 Mbit/s

Maximum data transfer rate (2.4 GHz)

573.50 Mbit/s

5 GHz

✓

6 GHz

✗

2.4 GHz

✓

Weight & dimensions

Weight

400 g

Height

159.50 mm

Depth

48.50 mm

Width

48.50 mm

Power

AC input voltage

44 - 57 V

Input current

0.32 A

Power consumption (max)

11.40 W

Power over Ethernet (PoE)

✓

Design

International Protection (IP) code

IPX5

Housing material

Aluminium, Plastic, Polycarbonate (PC)

Reset button

✓

LED indicators

Yes

Antenna direction type

Omni-directional

Computer system

Antenna type

Internal

Packaging content

Quick start guide

✓

Mounting kit

✓

AC adapter included

✓

PoE adapter included

✓

Network

Bluetooth

✓

Networking standards

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3af

VLAN support

✓

Cabling technology

10/100/1000Base-T(X)

MIMO type

Multi User MIMO

Ethernet LAN data rates

10, 100

Ports & interfaces

Ethernet LAN (RJ-45) ports

Operational conditions

Operating relative humidity (H-H)

5 - 95 %

Technical details

Sustainability compliance

✓

Certification

CE, FCC, IC

Compliance certificates

CE, Federal Communications Commission (FCC), Industry Canada (IC)

Logistics data

Harmonized System (HS) code

85176990

Product Details

Indoor/outdoor, 4x4 WiFi 6 access point designed for mesh applications. The Access Point WiFi 6 Mesh (U6 Mesh) is a high-performance, four-stream WiFi 6 access point that provides best-in-class signal meshing to enhance the wireless coverage of home and enterprise networks. The U6 Mesh can reach an aggregate throughput rate up to 5.3 Gbps with its 5 GHz (4x4 MU-MIMO and OFDMA) and 2.4 GHz (2x2 MIMO) bands. This access point also operates at full 4x4 MIMO with 160 MHz channels to create high-capacity wireless uplinks and facilitate faster data transfer. The sleek U6 Mesh is discreet enough to stage anywhere in your home or office, but also rugged enough to reliably operate outdoors thanks to its IPX5-rated, waterproof housing. The U6 Mesh is a plug-and-play device designed to easily extend your wireless signal to ensure full, seamless coverage and high-quality WiFi connectivity. It can be set up in minutes and fully managed with the UniFi Network web application or mobile app.

Files

User manual

mmo_120707558_1721286059_3593_37.pdf

PDF• 562.1 KB

Product Brochure

mmo_99134587_1651501223_4943_23546.pdf

PDF• 1.8 MB
