Ubiquiti AF-5XHD

Name: Ubiquiti AF-5XHD
Brand: Ubiquiti
SKU: 348335
Availability: InStock

Best offer

AED

1 390⁰⁰

AED

1 647⁰⁰

-15%

Key Features

2.4 GHz: No
5 GHz: Yes
Antenna gain level (max): 23dBi
Maximum data transfer rate: 1000Mbit/s
Channels quantity: 8channels
Placement: Pole, Wall
Number of connectors: 3
Throughput data rate: 1340Mbit/s
Frequency band: 4.8 - 6.2 GHz, 5.150 - 5.250 / 5.740 - 5.850 GHzGHz
Antenna connector type: RP-SMA
Internal: No
Antenna type: External
Channel bandwidth: 100MHz
Ethernet LAN data rates: 10, 100Mbit/s
Modulation: 1024-QAM, 16-QAM, 256-QAM, 4096-QAM, 64-QAM, QAM, QPSK

Specifications

Features

GPS (satellite)

✓

Operating system installed

AirOS

Security algorithms

256-bit AES

Maximum outdoor range

200000 m

MIMO

✓

Product colour

White

Antenna gain level (max)

23 dBi

Maximum data transfer rate

1000 Mbit/s

Channels quantity

8 channels

Placement

Pole, Wall

Number of connectors

Throughput data rate

1340 Mbit/s

Frequency band

4.8 - 6.2 GHz, 5.150 - 5.250 / 5.740 - 5.850 GHz

Antenna connector type

RP-SMA

5 GHz

✓

2.4 GHz

✗

Weight & dimensions

Weight

350 g

Height

224 mm

Depth

48 mm

Width

82 mm

Power

Output current

1 A

AC input voltage

20 - 50 V

Output voltage

24 V

Power consumption (max)

12 W

Power over Ethernet (PoE)

✓

Performance

Transmitting power

29 dBmW

Design

International Protection (IP) code

IP67

Internal

✗

Computer system

Built-in processor

✓

Antenna type

External

Packaging content

Mounting kit

✓

Network

Channel bandwidth

100 MHz

Ethernet LAN data rates

10, 100

Ports & interfaces

DC-in jack

✓

Ethernet LAN (RJ-45) ports

Technical details

Certification

CE, FCC, IC

Receiver

Receiver sensitivity

-69 dBm

Logistics data

Harmonized System (HS) code

85176990

Radar

Modulation

1024-QAM, 16-QAM, 256-QAM, 4096-QAM, 64-QAM, QAM, QPSK

Product Details

The New Standard for WISP Backhaul Performance True 1Gbps+ Spectrally Efficient, Noise Resilient PTP Technology Specifically Designed for WISP’s Complete Custom Hardware for the WISP, right down to the Silicon Our core communications processing engine surpasses all of the limitations inherent to generic Wi‐Fi chips. Game-Changing LTU Technology Spectral Efficiency Comparison of 802.11n, 802.11ac, airFiber Original, and LTU by year. IP-67 Durability airFiber 5XHD is Water Resistant and Perfect for any Weather Conditions.

Files

Product Brochure

mmo_65492362_1544601271_6518_3677.pdf

PDF• 7.1 MB

User manual

mmo_65492362_1544601278_1409_21154.pdf

PDF• 6.1 MB
