**5G Industrial Router – Key Specifications**
---
#### **Mobile Connectivity**
* **5G Sub-6GHz SA/NSA**:
* Download: Up to 3.4 Gbps (4x4 MIMO)
* Upload: Up to 900 Mbps (2x2 MIMO)
* **4G LTE Cat 20**:
* Download: Up to 2.0 Gbps
* Upload: Up to 210 Mbps
* **3G UMTS**:
* Download: 42 Mbps
* Upload: 5.76 Mbps
* **3GPP Release**: Release 16
* **SIM Support**:
* 2 x Mini SIM (2FF) slots + optional eSIM
* Auto-switch for signal strength, roaming, limits, failures
* **Band Management**:
* Band lock, used band status display
* Operator allow/block list by country
* **SIM Idle Protection**: Periodic switch to avoid SIM blocking
* **APN**: Auto APN
* **Passthrough & Bridging**: Assign WAN IP to LAN device or direct bridge
---
#### **Wi-Fi (Wireless)**
* **Wi-Fi 6 (802.11ax)**
* Dual Band (2.4GHz up to 576 Mbps / 5GHz up to 2402 Mbps)
* MU-MIMO, Wireless Mesh (802.11s)
* **Simultaneous Users**: Up to 512
* **Security**: WPA2, WPA3, EAP-TLS, 802.11w (PMF)
* **SSID Features**: Hidden ESSID, MAC filter, QR code login
* **Fast Roaming**: 802.11r, 802.11k, 802.11v
* **TravelMate**: Wi-Fi hotspot forwarding
---
#### **Ethernet**
* **WAN**: 1 x RJ45 (10/100/1000 Mbps, auto MDI/MDIX)
* **LAN**: 4 x RJ45 (10/100/1000 Mbps)
* **PoE (Passive)**:
* On LAN1, 9–30 VDC (Mode B), available from HW rev 0003
---
#### **Routing & Network Protocols**
* **Routing**: Static, Dynamic (OSPF, BGP, RIP, EIGRP)
* **Protocols**: TCP/IP, IPv4/IPv6, MQTT, SNMP, Telnet, DNS over HTTPS
* **VPN Support**:
* OpenVPN, IPsec, WireGuard, PPTP, L2TP, GRE, SSTP, DMVPN, Tinc, ZeroTier, Tailscale
* **QoS / SQM**: Traffic prioritization by service/protocol
* **Firewall**:
* Port forwarding, NAT, DMZ, DoS protection
* Preconfigured rules & CLI configuration
* **Hotspot Features**:
* Captive portal, Radius authentication, SSO, Hotspot 2.0
* 9 customizable themes
* **Connection Failover & Load Balancing**
* **DDNS**: 25+ providers supported
* **Visual Network Topology Display**
---
#### **Security**
* **Authentication**: Pre-shared key, RADIUS, TACACS+, X.509 certs
* **Access Control**: SSH, Web UI, Telnet, CLI
* **Attack Prevention**:
* SYN flood, SSH & HTTPS brute-force, port scan
* **VLAN**: Port/tag-based
* **Web Filter**: Blacklist/Whitelist for content control
---
#### **Industrial IoT Protocols**
* **Modbus**: TCP & USB, Client/Server, custom register support
* **OPC UA**: TCP (Client & Server modes)
* **DLMS/COSEM**: TCP, USB (Client mode)
* **DNP3**: Station, Outstation (TCP)
* **MQTT Gateway**: Supports Modbus-to-MQTT
---
#### **Cloud/Platform Integration**
* **IoT Platforms**:
* ThingWorx, Cumulocity, Azure IoT Hub, AWS IoT Core
* Plug & Play, Direct Methods, Device Provisioning
* **Data to Server**:
* HTTP(S), MQTT, Azure MQTT, AWS Kinesis
* Lua scripting support for data aggregation
* **API**:
* JSON-RPC, Teltonika Web API (Beta), TR-069
---
#### **Device Management & Monitoring**
* **Web UI**: HTTPS/HTTP, event log, kernel log
* **Remote Management**: Teltonika RMS
* **Firmware Updates**:
* FOTA, manual upload, configuration backups
* **CLI/SSH**: Busybox shell, SSH v1/v2
* **SNMP**: v1, v2, v3 + Trap
* **Email/SMS Alerts**: System & service notifications
* **Scheduled Events**: I/O-based triggers, SMS actions
---
#### **Hardware**
* **CPU**: Mediatek Dual-core 1.3 GHz (ARM Cortex A53)
* **RAM/Storage**: 512MB DDR3 RAM, 16MB NOR + 512MB NAND Flash
* **USB Port**: USB 2.0, supports file share, printer, serial adapter
* **Digital I/O**:
* Input: 0–6V (low), 8–50V (high)
* Output: Max 50V, 300mA
* **GNSS**: GPS, GLONASS, BeiDou, Galileo, QZSS
* **Antenna Connectors**:
* 4 x SMA (Mobile), 3 x RP-SMA (Wi-Fi), 1 x SMA (GNSS)
---
#### **Power & Physical**
* **Power Input**: 9–50 VDC
* **Consumption**: Idle < 4.5 W / Max < 13.5 W
* **Size**: 130.4 x 42.6 x 103.4 mm
* **Weight**: 452g
* **Casing**: Anodized aluminum, IP30 rated
* **Mounting Options**: DIN rail, wall mount (kit required)
* **Operating Temp**: -40°C to +75°C
* **Humidity**: 10% to 90% non-condensing
---
#### **Certifications**
* **Regulatory**: CE, UKCA, CB, RoHS, REACH
* **Vehicle**: E-mark (ECE R10, R118)
* **EMC Standards**: EN 55032, EN 55035, EN 61000 series, EN 301 489 series
