StarTech.com I51G-ETHERNET-SWITCH 5-Ports

Best offer
AED
35820

Key Features

  • Switch layer: L2
  • Basic switching RJ-45 Ethernet ports quantity: 5
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • Store-and-forward: Yes
  • Gigabit Ethernet (copper) ports quantity: 5
  • Half duplex: Yes
  • Jumbo frames: 9000
  • Wall mountable: Yes
  • Power LED: Yes
  • Switching capacity: 2Gbit/s
  • Maximum data transfer rate: 2000Mbit/s
  • Full duplex: Yes
  • Maximum data transfer rate: 0.1Gbit/s
  • MAC address table: 4000entries
  • DIN rail mounting: Yes
  • Offers
  • Price History
  • Specifications
  • Product Details
  • Review IconReviews
  • Community & Expert Opinions

Specifications

Features

Mean time between failures (MTBF)
1179133 h
Compatible operating systems
Linux, Mac, Windows
Plug and Play
✓
Maximum cable length
100 m
Screws included
✓
Quality of Service (QoS) support
✓
Rack mounting
✗
Connectivity technology
Wired
Product colour
Black
Wall mountable
✓
Power LED
✓
Switching capacity
2 Gbit/s
Maximum data transfer rate
2000 Mbit/s
Full duplex
✓
Maximum data transfer rate
0.10 Gbit/s
MAC address table
4000 entries
DIN rail mounting
✓
Jumbo frames support
✓
Switch layer
L2

Packaging data

Package weight
331 g
Package height
65 mm
Package depth
208 mm
Package width
168 mm

Weight & dimensions

Weight
122 g
Height
26 mm
Depth
140 mm
Width
90 mm

Power

Power connector
DC-in jack, Terminal block (3-pin)
Output current
0.60 A
Output voltage
48 V
Power plug type
Type M
AC input voltage
100 - 240 V
Power consumption (typical)
3.63 W
AC input frequency
50 - 60 Hz
DC input voltage
9 V
Input current
0.3 A
Power consumption (max)
60 W
Power over Ethernet (PoE)
✗
Input voltage
12 - 58 V
Number of power supply units
1
Output power
64.80 W
Power source
AC/DC
Redundant power supply (RPS) support
✗

Other features

Relative humidity
10 - 90 %
Supported data transfer rates
10/100 Mbps
Buffer size
128 KB
Networking features
Fast Ethernet

Design

International Protection (IP) code
IP30
Housing material
Metal, Plastic, Steel
LED indicators
Activity, Link, PoE, Power, Yes

Packaging content

Quick start guide
✓
Manual
✓
Cables included
AC
Power supply included
✓
AC adapter included
✓
Mounting bracket(s) included
✓
DIN rail included
✓
Wall mounting kit
✓
Terminal block included
✓

Network

Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Supported network protocols
CSMA/CD
Auto MDI/MDI-X
✓
Ethernet LAN data rates
10, 100
MAC address auto-learning supported
✓
MAC address auto-aging supported
✓
Auto-negotiation
✓
Ethernet interface type
Fast Ethernet
Ethernet LAN
✓
Fiber ethernet cabling technology
100BASE-FX
Copper ethernet cabling technology
1000BASE-T, 1000BASE-TX, 100BASE-TX, 10BASE-T
10G support
✗
Link aggregation
✓
Flow control support
✓
Jumbo frames
9000
Half duplex
✓
Store-and-forward
✓

Ports & interfaces

Power over Ethernet (PoE) ports quantity
2
Gigabit Ethernet (copper) ports quantity
5
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity
5

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 90 %
Storage relative humidity (H-H)
10 - 90 %
Storage temperature (T-T)
0 - 50 °C

Technical details

Regulatory Approvals
EN61000-4-8
Certification
CE, FCC, REACH, RoHS
Switch type
Unmanaged
Compliance certificates
RoHS, Trade Agreements Act (TAA)

Security

MAC address filtering
✓

Logistics data

Harmonized System (HS) code
85176990
Master (outer) case height
350 mm
Master (outer) case length
295 mm
Master (outer) case width
430 mm

Product Details

This PoE-powered switch expands your Gigabit network connectivity to remote locations where a power source is not available. For more versatility, you can power and network your Gigabit PoE-powered devices (PD) using two 802.3af PSE (Power Sourcing Equipment) ports. Its durable metal housing and redundant power input make this 5-port switch ideal for harsh environments. PoE-powered device (PD) provides installation flexibility The Gigabit network switch is powered through your existing PoE network infrastructure, so you can deploy it without an external power adapter. This gives you the flexibility to install the switch exactly where you need it, without additional hassle or costs. Plus, the switch supports the most common types of PoE power input, including 802.3af/at networks, so you can rest assured that it will be compatible with your PoE equipment. Integrated PSE ports can save you money This Power over Ethernet switch features two 802.3af ports, so you can deliver both power and data to your PoE PDs without the expense of additional PoE injectors or switches. The switch provides 15W of total power output across both ports, so you can power and connect PoE devices such as IP phones and cameras in situations where a typical AC-powered network device can’t be used. For applications where a power source is available, you can connect the optional power adapter and deliver up to 15W to each PSE port. Redundant power input gives you peace of mind The 5-port Gigabit Ethernet switch offers redundant power input using the included power adapter. With both PoE and AC power input, the versatile switch can remain operational during power dips, failures, or outages, making it perfect for factories, warehouses, and other industrial environments. The IES51GPOEPD is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Files

User manual

mmo_123028736_1730211995_3692_4044238.pdf

PDF• 395.4 KB

Product Brochure

mmo_123028736_1730211996_9457_3868073.pdf

PDF• 89.7 KB
