S3520 Series - 760 GB M.2

S3520 Series - 760 GB M.2

Intel S3520 Series - 760 GB M.2

Unavailable

Key Features

NAND flash type: MLC (Multi Level Cell)
Random read (100% span): 51000IOPS
Random write (100% span): 12500IOPS
Write latency: 50µs
Read latency: 46µs
Component for: Server/workstation
SSD temperature monitoring: Yes
End-to-End Data Protection: Yes
Enhanced Power Loss Data Protection technology: Yes
Uncorrectable Bit Error Rate (UBER): < 1 per 10^17 bits read
Data transfer rate: 6Gbit/s
Power consumption (idle): 0.6W
Power consumption (average): 2.7W
SSD form factor: M.2
SSD capacity: 760GB

Specifications

Features

Product series

Intel® SSD DC S3520 Series

Launch date

Q1'17

Mean time between failures (MTBF)

2 h

Market segment

Server

Security algorithms

256-bit AES

Lithography

16 nm

Product colour

Green

Uncorrectable Bit Error Rate (UBER)

< 1 per 10^17 bits read

Data transfer rate

6 Gbit/s

Power consumption (idle)

0.60 W

SSD temperature monitoring

✓

Component for

Server/workstation

NAND flash type

MLC (Multi Level Cell)

Weight & dimensions

Weight

9 g

Depth

80 mm

Width

22 mm

Power

Power consumption (average)

2.70 W

Other features

Product family

Data center SSD

SSD weight

9 g

SSD hardware encryption

AES 256 bit

SSD power consumption (active)

2.7 W

SSD power consumption (idle)

600 mW

SSD endurance rating

1420 TBW

Product brief URL

http://www.intel.com/content/www/us/en/solid-state-drives/ssd-dc-s3520-brief.html

SSD shock

1000G/0.5ms

Drive capacity

760 GB

Sequential writing speed

270 MB/s

Sequential reading

400 MB/s

Intel Rapid Start Technology version

0

SSD ARK ID

93003

Intel High Endurance Technology (HET)

✗

Processor special features

Intel Smart Response Technology version

0.00

Intel® Rapid Start Technology

✗

Intel® Smart Response Technology

✗

Storage

SSD form factor

M.2

SSD capacity

760 GB

Ports & interfaces

Interface

Serial ATA III

Operational conditions

Operating temperature (T-T)

0 - 70 °C

Non-operating vibration

3.13 G

Operating vibration

2.17 G

Non-operating shock

1000 G

Operating shock

1000 G

Technical details

Product codename

Downieville

Last change

63903513

Status

Discontinued

Security

Hardware encryption

✓

Enhanced Power Loss Data Protection technology

✓

End-to-End Data Protection

✓

Solid state drive

Read speed

400 MB/s

Write speed

270 MB/s

Memory type

MLC

Read latency

46 µs

Write latency

50 µs

Random write (100% span)

12500 IOPS

Random read (100% span)

51000 IOPS

Product Details

The most trusted SATA SSD now on Intel 3D NAND. Modernize your data center storage and make the switch from HDDs to the Intel® SSD DC S3520 Series. As part of the Intel® 3D NAND SSD family of products, the Intel SSD DC S3520 Series delivers the unmatched combination of data integrity, performance consistency, and drive reliability. With a much lower active write power than the Intel® SSD DC S3510 Series, the Intel SSD DC S3520 Series enables the delivery of 35% more rack performance per watt. With a competitive IOPs/$, the Intel SSD DC S3520 Series is the ideal replacement for HDDs.
