Intel P3520 - 2 TB 2.5-inch

Unavailable

Key Features

Random read (100% span): 320000IOPS
Random write (100% span): 26000IOPS
Write latency: 20µs
Read latency: 20µs
SSD temperature monitoring: Yes
End-to-End Data Protection: Yes
Enhanced Power Loss Data Protection technology: Yes
Power consumption (idle): 4W
Power consumption (read): 9W
Power consumption (write): 11W
PCI Express interface data lanes: x4
SSD capacity: 2000GB
SSD form factor: 2.5"
Internal: Yes
Hardware encryption: Yes

Specifications

Features

Mean time between failures (MTBF)

2000000 h

Product colour

Silver

Power consumption (idle)

4 W

SSD temperature monitoring

✓

Weight & dimensions

Weight

125 g

Power

Power consumption (read)

9 W

Power consumption (write)

11 W

Other features

SSD ARK ID

88727

SSD usage tag

Data center

TBW rating

2490

Intel High Endurance Technology (HET)

✗

PCI Express interface data lanes

Storage

SSD capacity

2000 GB

SSD form factor

2.5"

Design

Internal

✓

Ports & interfaces

Interface

PCI Express

Operational conditions

Operating temperature (T-T)

0 - 35 °C

Non-operating vibration

3.13 G

Operating vibration

2.17 G

Non-operating shock

1000 G

Operating shock

1000 G

Security

Hardware encryption

✓

Enhanced Power Loss Data Protection technology

✓

End-to-End Data Protection

✓

Solid state drive

Memory type

MLC

Read speed

1700 MB/s

Write speed

1350 MB/s

Read latency

20 µs

Write latency

20 µs

Random write (100% span)

26000 IOPS

Random read (100% span)

320000 IOPS

Product Details

Maximum Value Meets Maximum Performance With the Intel® SSD DC P3520 Series, you can now transition your data center storage solutions from SATA SSDs and HDDs in a cost-effective manner. Built on Intel 3D NAND, the Intel® SSD DC P3520 Series is optimized for high density data center/enterprise configurations. Combined with the low latency and high bandwidth of the NVMe specification, the Intel® DC P3520 Series enables up to 4.7x the performance of SATA―making it ideal for read-intensive workloads. The consistently amazing performance of the Intel® SSD DC P3520 Series provides fast data streams directly to the processor, such as the high-performance Intel® Xeon® processor, for efficient server data transfers. The Intel® SSD DC P3520 Series is built with the data integrity, drive reliability, and performance consistency you expect from Intel.
