Enhanced Power Loss Data Protection technology: Yes
Uncorrectable Bit Error Rate (UBER): < 1 per 10^17 bits read
Power consumption (idle): 5W
Power consumption (average): 12.5W
PCI Express interface data lanes: x4
NVMe: Yes
Specifications
Features
Product series
Intel® SSD DC P4501 Series
Launch date
Q2'17
Mean time between failures (MTBF)
2000000 h
Market segment
Server
Security algorithms
256-bit AES
Product colour
Silver
Uncorrectable Bit Error Rate (UBER)
< 1 per 10^17 bits read
Power consumption (idle)
5 W
SSD temperature monitoring
✓
Component for
Server/workstation
NAND flash type
TLC (Triple Level Cell)
Weight & dimensions
Weight
13 g
Height
7 mm
Depth
110 mm
Width
22 mm
Power
Power consumption (average)
12.50 W
Other features
Product family
Data center SSD
SSD weight
64 g
SSD hardware encryption
AES 256 bit
SSD power consumption (active)
up to 10 or 12.5W
SSD power consumption (idle)
<5 W
SSD endurance rating
1.85 PBW
SSD shock
1000 G/0.5 msec
Random read (8GB span)
285000 IOPS
Random write (8GB span)
41000 IOPS
Drive capacity
1000 GB
Remote Secure Erase (RSE) technology version
0.00
Sequential writing speed
620 MB/s
Sequential reading
3100 MB/s
Intel Rapid Start Technology version
0
SSD ARK ID
96927
SSD usage tag
Data center
TBW rating
1830
Intel High Endurance Technology (HET)
✗
PCI Express interface data lanes
x4
Processor special features
Intel Smart Response Technology version
0.00
Intel® Rapid Start Technology
✗
Intel® Smart Response Technology
✗
Storage
NVMe
✓
SSD form factor
2.5"
SSD capacity
1000 GB
Ports & interfaces
Interface
PCI Express 3.1
Operational conditions
Operating temperature (T-T)
0 - 70 °C
Non-operating vibration
3.13 G
Operating vibration
2.17 G
Non-operating shock
1000 G
Operating shock
1000 G
Technical details
Product codename
Cliffdale
Last change
63903513
Status
Launched
Security
Hardware encryption
✓
Enhanced Power Loss Data Protection technology
✓
End-to-End Data Protection
✓
Brand-specific features
Intel® Remote Secure Erase
✗
Solid state drive
Read speed
3200 MB/s
Write speed
640 MB/s
Memory type
3D TLC
Read latency
100 µs
Write latency
30 µs
Random write (100% span)
36000 IOPS
Random read (100% span)
275000 IOPS
NVMe version
1.2
Product Details
This low power drive enables energy and space efficient storage solutions to help data centers do more per server, minimize service disruptions and efficiently manage at scale.
Power-Efficient, High Performance SSDs Optimized for Cloud Storage
This cloud-inspired SSD is built with an entirely new NVMe controller, optimized for read intensive workloads and designed to maximize CPU utilization. With the Intel SSD DC P4501 Series, data centers can increase users, add more services, and perform more workloads per server. Now you can store more and know more.
Optimized Solutions for Space and Power Efficiency
Available in U.2 (2.5 in x 7mm) and M.2 (110mm x 22mm) form factors, and optimized for high performance-per-watt, power efficiency, and low power envelopes, this SSD enables new opportunities to maximize storage capacity without incurring the power demands of larger, space-consuming form factors.
Outstanding Quality and Reliability
With industry-leading quality and reliability, you can be confident your drives are available and your data is protected. Support for data-at-rest encryption minimizes the likelihood of data breaches, while industry-leading end-to-end data protection reduces the chance of silent data errors.
Advanced Manageability and Serviceability
Built with advanced manageability features such as NVMe-MI, the Intel SSD DC P4501 Series allows you to remotely monitor, manage and remediate across more device states and streamline essential services.
