ETCR6300D DC clamp-on leakage current meter is specially designed and manufactured for measuring DC leakage current and small DC current, with a resolution of up to 0.1mA. The instrument adopts CT technology and digital integration technology, which has the characteristics of small size, high precision and perfect function. It is widely used in electric power, communications, meteorology, railways, oil fields, construction, measurement, scientific research and teaching units, industrial and mining enterprises, automobile circuit maintenance and other fields. The sensor core is made of high-permeability alloy, and adopts multi-layer shielding technology, which has strong anti-interference ability, ensuring high precision, high stability and high reliability for year-round uninterrupted measurement.
The ETCR6300D DC Clamp Leakage Current Meter has a USB interface, and its software can be online real-time monitoring and historical query, dynamic display, with historical data reading, saving, printing and other functions. The meter also has functions such as peak value hold, data hold, data storage, and zero reset.
Function: DC leakage current measurement, DC current measurement, car leakage maintenance
Power source: Alkaline dry battery 6LR61 9V DC, about 20 hours of continuous use
Test method: Clamp CT, magnetic modulation
Measuring range: 0.0mA～6.00A DC
Resolution: 0.1mA DC
Measurement accuracy: (23℃±3℃, below 70%RH)
0.0mA～300.0mA DC: ±2%rdg±5dgt
0.30A～6.00A DC: ±2%rdg±5dgt
Meter weight: about 120g (including battery)
Instrument size: height, width and thickness: about 175mm×70mm×38mm
Jaw size: 25mm×30mm
LCD size: 35mm×21.5mm; display area: 32mm×15mm
Sampling rate: about 2 times/sec
Display mode: 4-digit LCD display
Zero reset function: Yes, you can reset by pressing the ZERO button before testing
Communication interface: with USB interface, storage data can be uploaded to the computer, sof
