EMUKOEP 6450

1. High performance, as well as high reliability, high safety, automatic measuring range, hand-held collet ammeter, etc. features. 2. It has widescreen digital, full overload protection, data retention, low voltage display, auto off function. 3. True RMS measurement can accurately measure frequency voltage, non-sinusoidal voltage, and can measure fluctuation , surge (RMS). 4. Variable frequency power supply, air conditioning and refrigerator and other cooling equipment and engine performance tests, etc. Suitable for . 5. DC range function, electroplating, dc welding machine, automatic detection and all kinds of DC measurement above 500mA. Specification: Condition:100% Brand New Item type: Collet Meter Material: ABS Colour: As shown in the picture Main function Range Resolution Accuracy DC Voltage 400mV 0.1mV ±(0.8%+2d) 4V 1mV 40V 10mV 400V 100mV 1000V 1V ±(1% +3d) AC Voltage 400mV 0.1mV ±(1.2+5d) 4V 1mV 40V 10mV 400V 100mV 700V 1V ±(1.5%+5d) DC i 40A 10mA ±(2% +10d) 400A 100mA ±(2+5d) 1000A 1A AC i 40A 10mA ±(2% +10d) 400A 100mA ±(2+5d) 700A 1A Resistance Ω 400Ω 0.1Ω ±(1%+5d) 4KΩ 1Ω 40KΩ 10Ω 400KΩ 100Ω 4MΩ 1KΩ 40MΩ 10KΩ ±(1.5+5d) Capacitance 10nF 0.001nF ±(3%+5d) 100nF 0.01nF 1uF 0.1nF 10uF 1nF 100uF 10nF 1000uF 100nF 10mF 1uF ±(5%+5d) Frequency 10HZ 0.001HZ ±(0.5%+3d) 100Hz 0.01Hz 1KHZ 0.1HZ 10KHz 1HZ 100KHz 10Hz 1MHZ 100Hz 10MHz 1KHz Duty cycle 1%~99%0.001±(0.5%+3 days) Temperature -50-300°C 1°C ±(1+4d) -1000°C 1°C ±(1.9+5d) -58-600°F 1°F ±(1.2%+6) 601-1832°F 1°F ±(1.9%+6) Input impedance Approx 10MΩ Auto range Support Support manual range Actual RMS Support Entry protection Support
