XTGHL DC Ammeter

Feature: Self-power Measurement Range: 6V ~ 80V Measuring Range with External Power Supply: 0~500V Input Current Measurement Range: 0~100A External Supply Voltage: 6-60V Display Mode:2.4 inch color LCD display Voltage: 0.01V~500V Current: 50A ,100A, 200A ,300A ,500A ,Can choose(Notice:If you want measuring less than 1A current ,pls choose the 50A Meter ) Specification: 1. Capacity: 0.001AH~65000.00AH, Energy: 0.000KWH~9999KWH,Time: 0 ~ 100 hours, Power Value: 999KW 2. Temperature: 1~100°C, Voltage: ± 1% + 2 words, Current: ± 2% + 5 words, Temperature: ± 1.5 ℃, Measurement Rate: 5 times / second 3. Relay Delay Time: (0-60)S, Communication Distance: Open single group 10 meters, OVP (Overvoltage protection): 0.01V~500V, LVP (Undervoltage protection): 0.01~500V 4. OCP (Charge Overcurrent Protection): 0-500A, NCP (Discharge overcurrent protection): 0-500A, Display Board Size: 87 * 49 * 14 mm/3.4*1.9*0.6in, Measuring Plate Size: 114 * 54 * 28 mm/4.5*2.1*1.1in
