D-Link DES-1005D 5-ports

Key Features

  • Switch layer: L2
  • Basic switching RJ-45 Ethernet ports quantity: 5
  • Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
  • Store-and-forward: Yes
  • Power LED: Yes
  • Switching capacity: 1Gbit/s
  • Full duplex: Yes
  • Maximum data transfer rate: 0.2, 1Gbit/s
  • MAC address table: 8000entries
  • Access Control List (ACL): No
  • Data transfer rate: 1000Mbit/s
  • Jumbo frames support: Yes
  • Forwarding rate: 0.1488Mpps
  • Power source: AC
  • Packet transfer speed: 14880 - 148800 p/s
  • Offers
  • Price History
  • Specifications
  • Product Details
  • Review IconReviews

Specifications

Features

Safety
CSA
Plug and Play
✓
Cloud-managed
✗
Quality of Service (QoS) support
✓
Rack mounting
✗
Stackable
✗
Connectivity technology
Wired
Product colour
White
Packet buffer memory
0.11 MB
Power LED
✓
Switching capacity
1 Gbit/s
Full duplex
✓
Maximum data transfer rate
0.20Gbit/s, 1Gbit/s
MAC address table
8000 entries
Access Control List (ACL)
✗
Data transfer rate
1000 Mbit/s
Jumbo frames support
✓
Forwarding rate
0.15 Mpps
Switch layer
L2

Packaging data

Package weight
222 g
Package height
98 mm
Package depth
116 mm
Package width
100 mm

Weight & dimensions

Weight
80 g
Height
29.10 mm
Depth
83.40 mm
Width
125.30 mm

Management features

Web-based management
✗

Power

Power connector
DC-in jack
Power consumption (typical)
2.50 W
Input current
1.2 A
Power consumption (max)
3.80 W
Power over Ethernet (PoE)
✗
Input voltage
5 V
Power source
AC

Other features

Electromagnetic emissions
CE Mark
I/O ports
5x 10/100/1000BASE-T
Dimensions (WxDxH)
142 x 107 x 30 mm
Supported data transfer rates
10/20/100/200 Mb/s
Packet transfer speed
14880 - 148800 p/s

Design

Housing material
Plastic
Fanless
✓
LED indicators
Activity, Link, Power

Packaging content

User guide
✓
Batteries included
✗
Manual
✓
Cables included
AC
Power supply included
✓

Network

Data link protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Switching protocols
CSMA/CD
Networking standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Auto MDI/MDI-X
✓
Ethernet LAN data rates
10
MAC address auto-learning supported
✓
Auto-negotiation
✓
Copper ethernet cabling technology
1000BASE-T, 100BASE-TX, 10BASE-T
10G support
✗
Flow control support
✓
Store-and-forward
✓

Ports & interfaces

Cable types supported
Cat3, Cat4, Cat5, Cat5e
Basic switching RJ-45 Ethernet ports type
Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity
5

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 90 %
Storage relative humidity (H-H)
5 - 90 %
Heat dissipation
8.53 BTU/h

Technical details

Certification
C-Tick Class B, CB, CE Class B, FCC Class B, ICES-003 Class B, VCCI Class B, cUL
Pallet gross weight (sea)
411600 g
Pallet height (sea)
2020 mm
Pallet gross weight (air)
411600 g
Pallet height (air)
2020 mm
Switch type
Unmanaged

Logistics data

Harmonized System (HS) code
85176990
Pallet gross width
1200 mm
Shipping (inner) case gross weight
4910 g
Shipping (inner) case net weight
3280 g
Pallet gross length
1100 mm
Shipping (inner) case height
235 mm
Shipping (inner) case length
432 mm
Shipping (inner) case width
253 mm

Product Details

The DGS-1005D 5-Port Gigabit Desktop Switch is part of D-Link’s series of SOHO devices that allows you to easily expand and upgrade your network. D-Link’s Green Technology provides energy savings, reduces heat, and a longer product life without sacrificing performance or functionality. DGS-1005D provides five Gigabit ports for easy expansion of your network and a quick way to upgrade your network to Gigabit connectivity. An energy-efficient power adapter (EnergyStar Level V qualified), minimised use of harmful substances (RoHS compliant), and recyclable packaging make this switch truly environmentally friendly. Fast and Reliable Networking The D-Link DGS-1005D 5-Port Gigabit Desktop Switch creates a blazing fast network for your office, as its Gigabit Ethernet ports provide high-speed wired connections for up to five PCs or other devices. The DGS-1005D also features QoS, which prioritises network traffic so that time-sensitive data is delivered efficiently, even during bursts of high data traffic. It’s stylish, easy-to-use, and comes IPv6-ready for a reliable network today and tomorrow. Conserve Energy The 5-Port Gigabit Desktop Switch helps you conserve energy automatically through several methods. It automatically powers down ports that have no link, allowing the switch to save a substantial amount of power by cutting power usage for unused ports or ports connected to computers that have been shut down.

Files

Product Brochure

mmo_504628_1737625945_4256_131655.pdf

PDF• 805.9 KB
