TheCoolCube SensorA - Night Vision 580X540 pixels

Sony chip CCD Special Car Rear View Camera for: SUBARU Impreza Sedan SUBARU Forester SUBARU Outback (2007-2014) Sony chip CCD camera is high clear, better quality than the Sharp CCD & CMOS and CMD. Technique Parameter: Image sensors: 1/3" color Sony chip CCD TV System: NTSC default White Balance: Auto Video Color: Colorful Effective Pixels : 580X540 Resolution : 480 TV lines ( Regular CMOS/CMD is 420 TV line ) Video Output: 1.0Vp-p,75Ω Electronic Shutter: 1/60(NTSC)-1/10000S S/N ratio: Better Than 48db Operation Temperature: -20°C+80°C RH95% Working Power (DCV): 12V Current consumption: 90mA Max How to Install : -Take out your stock license plate light at the back of your car -Fix the camera to where the stock license plate light was -Connect the built-in license plate light of the camera to where the stock license plate light was connected to get the power -Connect the power of the camera to your back lights - red wire to positive and black wire to negative -Connect the video cable of the camera to the extension cord -Connect the extension cord to your car monitor
