1, Scope Name: Portable and Smart Screen
Product model: TX27G2W
2, Product Positioning
Different from traditional screens or TVs, the smart screen comes with universal wheels that follows you wherever you go.
One screen integrates functions such as long battery life, multi-terminal screen projection and screen rotation, completely getting rid of the shackles of cables, meeting your needs in living rooms, bedrooms, kitchens, and even offices, campsites and other venues, providing you with a new viewing experience anywhere, anytime, and at will.
3, Applications
Home Display:
Game interaction, private fitness, online class learning, watching movies, K songs, and listening to songs.
Commercial Display:
Meeting, design, advertising, promotion, live video streaming, business negotiation, and training.
Entertainment And Leisure:
......
Field:
Indoor and Outdoor
4, Specification
Display-1920p
Screen Size: 27 inch
Screen Type: LCD
Backlight Type: ELED
Resolution(pixels): 1920x1080(pixels)
Brightness: 380cd/m²（Typ）/330cd/m²（Min）
Contrast Ratio: 4000:1(Typ)
Response Time: 6.5ms(Typ)/12ms(Typ)
Pixel Pitch(mm): 0.1038(H)x0.3114(V) mm
Refreshing Frequency: 60Hz
Life Time: 30,000 hrs (min.)
Color Gamut(X%NTSC): NTSC 1931 65%(Typ)/62%(Min)
View Area(mm): 597.888(H)x336.312 (V) mm
Display Colors: 1.07 G colors
Electrical
Chipset: RK3588S
CPU---
Architecture: ARM Cortex-A76*4+ARM Cortex-A55*4
Working Frequency: ARM Cortex-A76:2.4GHz
ARM Cortex-A55:1.8GHz
Core: Hexa-core
GPU: Mali-G610 MP4, Quad- core
RAM: 8GB
ROM: 128GB
OS: Android 13
Mainboard Interface
HDMI*1--
Max Resolution: 2160P@60Hz
Version：HDMI 2.0
USB2.0*1, support images, music, video file playback
USB3.0*1, support images, music, video file playback
Camera & Microphone--
Front Camera: 800W
Microphone: Dual MIC
Touch: Supports ten-point capacitive touch
Maximum Audio Power: 2x5W(High pitch)＋2x5W(Mid-bass)
Structure--
Product Size(WxDxH): 634×426×1306mm
Package Size(WxDxH): 985x250x530mm
Housing Material(Frame/Back cover): Plastic
Net weight: 17.5KG
Gross weight: 22KG
5, Accessories
Screen Displayx1
Quick Installation Guidex1
Instruction manualx1
Adapterx1
Universal wheel basex1
Lifterx1
Screwsx5
Power cablex1
Remote controlx1
Built-in Webcamx1
6, Environment
Operating temperature：0℃ ~ + 40℃
Charging temperature：0℃ ~ +45℃
Operating humidity：0% ~ 65% RH Non-Condensing
Storage humidity：0% ~ 60% RH Non-Condensing
Operating altitude：≤3000m
