Intel SSDPEDME400G401 - 400GB M 2

Best offer
AED
1 05549

Key Features

  • Random read (4KB): 420000, 430000IOPS
  • Random write (4KB): 23000, 230000IOPS
  • Random read (8KB): 220000IOPS
  • Random write (8KB): 10000IOPS
  • Random read (100% span): 320000, 420000IOPS
  • Random write (100% span): 23000, 30000IOPS
  • Write latency: 20, 30µs
  • Read latency: 20, 120µs
  • SSD temperature monitoring: Yes
  • End-to-End Data Protection: No, Yes
  • Enhanced Power Loss Data Protection technology: Yes
  • Uncorrectable Bit Error Rate (UBER): < 1 per 10^16 bits read, < 1 per 10^17 bits read
  • Power consumption (idle): 4W
  • Power consumption (read): 8, 11W
  • Power consumption (write): 7, 25W

Specifications

Features

Product series
Intel 750, Intel DC P3500, Intel DC P3600
Launch date
Q1'15, Q2'14, Q2'15
Temperature monitoring and logging
Mean time between failures (MTBF)
1200000h, 2000000h
Market segment
Mobile, Server
Maximum operating altitude
3048m, 10000m
Lithography
20 nm
Product colour
Silver
Uncorrectable Bit Error Rate (UBER)
< 1 per 10^16 bits read, < 1 per 10^17 bits read
Power consumption (idle)
4 W
SSD temperature monitoring

Weight & dimensions

Weight
115g, 125g, 185g
Height
15 mm
Depth
100.50 mm
Width
69.80 mm

Power

Operating voltage
3.30 V
Power consumption (read)
8W, 11W
Power consumption (write)
7W, 25W

Performance

Maximum operating temperature
35°C, 55°C
Minimum operating temperature
0 °C

Other features

Product family
Consumer SSD, Data center SSD
Power consumption (active)
12 W
SSD weight
125 g
SSD power consumption (active)
12, 7W (read), 8W (write)
SSD power consumption (idle)
4, 4W
SSD endurance rating
2.19 PBW (JEDEC workload), 219 TBW, 70GB per day
Product brief URL
http://www.intel.com/content/dam/www/public/us/en/documents/product-briefs/intel-ssd-dc-family-for-pcie-brief.pdf, http://www.intel.com/content/dam/www/public/us/en/documents/product-briefs/ssd-750-brief.pdf
SSD shock
1000, 1000 G/0.5msec, 170 in/s, 50 G Trapezoidal, 50 G Trapezoidal 170 in/s
Random read (8GB span)
430000 IOPS
Random write (8GB span)
230000 IOPS
Drive capacity
400 GB
Sequential writing speed
550MB/s, 900MB/s, 1000MB/s
Sequential reading
2100MB/s, 2200MB/s
Intel Rapid Start Technology version
0
SSD ARK ID
80996, 82846, 82847, 86742
SSD usage tag
Consumer, Data center
Intel High Endurance Technology (HET)
Endurance rating
2.19 PB
PCI Express interface data lanes
x4

Processor special features

Intel Smart Response Technology version
0.00
Intel® Rapid Start Technology
Intel® Smart Response Technology

Storage

NVMe
SSD form factor
Half-Height/Half-Length (HH/HL)
SSD capacity
400 GB

Design

Internal

Ports & interfaces

Interface
PCI Express 3.0

Operational conditions

Operating / non-operating shock
1000, 1000 G/0.5msec, 170 in/s, 50 G Trapezoidal, 50 G Trapezoidal 170 in/s
Operating temperature (T-T)
[object Object],[object Object]
Non-operating vibration
3.13 G
Operating vibration
2.17 G
Non-operating shock
50G, 1000G
Operating shock
50 G
Maximum non-operating altitude
12192m, 40000m

Technical details

Product codename
Carmel Ridge, Fultondale, Pleasantdale
Last change
63903513
Status
Discontinued
Product name
1/2 Height PCIe 3.0, 2.5in PCIe 3.0, 20nm, Intel SSD DC P3500 Series (400GB, Intel SSD DC P3600 Series (400GB, MLC)
Born on date
Q1'15, Q2'14
Commodity Classification Automated Tracking System (CCATS)
G149950
Certification
BSMI, C-Tick, CE, KCC, Microsoft WHQL, UL, VCCI
Compliance certificates
RoHS

Processor

Processor lithography
20 nm

Security

Enhanced Power Loss Data Protection technology
End-to-End Data Protection

Expansion slots

PCI Express CEM revision
2.0

Logistics data

Export Control Classification Number (ECCN)
5A992C
Harmonized System (HS) code
8523510000

Solid state drive

Read speed
2100MB/s, 2200MB/s
Write speed
550MB/s, 900MB/s, 1000MB/s
Memory type
MLC
Read latency
20µs, 120µs
Write latency
20µs, 30µs
Random write (100% span)
23000IOPS, 30000IOPS
Random read (100% span)
320000IOPS, 420000IOPS
Random write (8KB)
10000 IOPS
Random read (8KB)
220000 IOPS
Random write (4KB)
23000IOPS, 230000IOPS
Random read (4KB)
420000IOPS, 430000IOPS

Product Details

Breakthrough performance – The Intel® Solid-State Drive Data Center Family for PCIe* brings extreme data throughput directly to Intel® Xeon® processors with up to six times faster data transfer speed than 6 Gbps SAS/SATA SSDs.1 The performance of a single drive from the Intel SSD Data Center Family for PCIe, specifically the Intel® Solid-State Drive Data Center P3700 Series (460K IOPS), can replace the performance of 7 SATA SSDs aggregated through a host bus adapter (HBA) (approximately 500K IOPS). Modernizes data center storage – Intel led the industry in creation of a new Non-Volatile Memory Express* (NVMe*) storage interface standard. NVMe overcomes SAS/SATA SSD performance limitations by optimizing hardware and software to take full advantage of NVM SSD technology. Comprehensive solution – Intel is driving transition to NVMe SSDs by providing a comprehensive product line, enabling extensive system compatibility, delivering Intel drivers as well as supporting industry driver development, and completing numerous industry standard compliance certifications. Proven quality and reliability – Intel SSD Data Center Family for PCIe devices are based on Intel-developed controller, firmware, and leading manufacturing process NAND flash memory. Rigorous qualification and compatibility testing ensures a highly reliable SSD. The Intel® SSD Data Center Tool provides a powerful set of management capabilities.
