Shenzhen D&C Security Technology Co.,Ltd DC-AHD180DV/IRH

D&C Security AHD 2.0MP 1080P 180 Degree Wide Angle Fisheye Camera,Replace multiple cameras with one camera Features: 1.180 Degree Panaromic Security Fish Eye Camera 2.Has a metal case, Indoor Outdoor, Night Vision, AHD 1080P Camera 3.15 pieces of IR LED's and OSD Control 4.Can be used for covering broader areas. Product Name: AHD 180 Degree IR Fish Eye Camera Model No.: DC-AHD180DV/IRH Imaging Sensor: 1/2.8" CMOS,2.0Megapixel , AHD-H output Lens: 180 degree fisheye lens Video Compression: H.264 Pixels: PAL:976 H x 582 V /NTSC:976 H x 494 V Scanning: 2:1 Interlace Sync Mode: Internal Horizontal and Vertical Frequency: PAL:15.625 kHz, 50.00 HZ / NTSC:15.734kHZ,59.94HZ Video Output: 1.0Vp-p/75Ω Composite video signal S/N Ratio: >60dB AGC Off AGC: Auto E-shutter: PAL:1/50-1/100,000 s / NTSC:1/60-1/100,000s Illumination: IR on 0 Lux Operating Temperature and humidity: -10c-50c,20%-90% RH Dimension: 105*84mm Weight: 0.38Kg Pls Notice: This camera is a 180 degree 2MP 1080P AHD Camera,so it need to work with a 2MP 1080P AHD DVR,and image can reach 1080P Resolution. However,we have made the camera with OSD buttons,so the camera can convert to analog working mode too. After power on, when no menu show on the screen, long press the button to the left side for about 10 seconds to change to analog mode. However,if you use this camera with analog system,as analog system do not have very high resolution,so the picture may not be as good as when you use the camera with a AHD DVR. And this camera do not have Split Software.
