Cisco SG500X-24 24-ports

Best offer
AED
3 36177

Key Features

  • Switch layer: L2/L3, L3
  • Physical stacking (units): 8
  • Basic switching RJ-45 Ethernet ports quantity: 24
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • Throughput: 95.24Mpps
  • DHCP features: DHCP client, DHCP relay, DHCP server, DHCP snooping
  • Uplink ports quantity: 4
  • Number of queues: 8
  • Number of static routes: 2048
  • Number of IP interfaces: 256
  • Static route: Yes
  • Number of multicast groups filtered: 1024
  • Gigabit Ethernet (copper) ports quantity: 24
  • Port mirroring: Yes
  • IP routing: Yes
  • Offers
  • Price History
  • Specifications
  • Product Details
  • Review IconReviews

Specifications

Features

Country of origin
China
Mean time between failures (MTBF)
246188.20 h
Compatible operating systems
Linux, Mac OS X, Microsoft Windows, Windows
Plug and Play
✓
Internal memory
256 MB
Processor frequency
800 MHz
MIB support
Y
Quality of Service (QoS) support
✓
Security algorithms
802.1x RADIUS, HTTPS, SNMPv3, SSH, SSH-2, SSL/TLS
Rack mounting
✓
Noise level
40.20 dB
Stackable
✓
Virtual LAN features
Multicast VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Stacked VLAN, Tagged VLAN, VLAN Identifier ( VLAN ID), Voice VLAN
Product colour
Black
Packet buffer memory
12 MB
Queue scheduling algorithms
Weighted Round Robin (WRR)
SFP+ module slots quantity
2
Telnet
✓
Access Control List (ACL)
✓
Sleep mode
✓
Access Control List (ACL) rules
3072
Switching capacity
128 Gbit/s
MAC address table
16384 entries
Authentication type
IEEE 802.1x
Jumbo frames support
✓
Forwarding rate
95.24 Mpps
Multicast support
✓
Static route
✓
Switch layer
L2/L3, L3

Packaging data

Package weight
4560 g
Package height
108 mm
Package depth
545.10 mm
Package width
388.10 mm

Weight & dimensions

Weight
3450 g
Height
44 mm
Depth
440 mm
Width
440 mm

Management features

Web-based management
✓
Firmware upgradeable
✓
System event log
✓
ARP inspection
✓
Number of multicast groups filtered
1024

Power

Power plug type
Type C
Power consumption (typical)
36.20 W
AC input voltage
100 - 240 V
AC input frequency
47/63 Hz
Power consumption (max)
32.50 W
Power over Ethernet (PoE)
✗
Total Power over Ethernet (PoE) budget
375 W
Redundant power supply (RPS) support
✓

Performance

Physical stacking (units)
8

Wireless LAN features

IGMP snooping
✓

System requirements

Minimum system requirements
Safari v5+

Software

Virtual Router Redundancy Protocol (VRRP)
✓

Design

Stacking
✓
Reset button
✓
LED indicators
Link, PoE, Yes
Form factor
1U

Computer system

Built-in processor
✓

Packaging content

Packaging content
Rubber feet
Included power plug types
AU
Quick start guide
✓
Resource CD
✓
Cables included
AC, Serial
Power supply included
✓
Mounting bracket(s) included
✓
Rack mount kit
✓

Network

Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Supported network protocols
TCP/IP
Management protocols
CLI, HTTP, HTTP/HTTPS, HTTPS, IPv4, IPv6, MIB, Ping, RMON, RMON1, RMON2, RMON3, RMON9, SNMP, SNMP v1/v2c/v3, SNMP1, SNMPv1, SNMPv2c, SNMPv3, SNTP, SSH, Syslog, TACACS, TFTP, Telnet, Telnet Server/SSH, Traceroute, Web/SSL
VLAN support
✓
Number of VLANs
4096
Spanning tree protocol
✓
Head-of-line (HOL) blocking
✓
Rate limiting
✓
Active link detection
✓
Cable length detection
✓
MAC address auto-learning supported
✓
Flow control support
✓
IPv4 routes
2048
IPv6 routes
2048
Copper ethernet cabling technology
1000BASE-T, 100BASE-TX, 10BASE-T
10G support
✓
Link aggregation
✓
Jumbo frames
9216
Port mirroring
✓

Ports & interfaces

Power over Ethernet (PoE) ports quantity
24
Fiber optic connector
SFP
SFP module slots quantity
2
Cable types supported
Cat5, Cat5e, Cat6, Cat6a, Cat7, Fiber
Console port
RJ-45
USB 2.0 ports quantity
1
Combo SFP ports quantity
2
Gigabit Ethernet (copper) ports quantity
24
Uplink ports quantity
4
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity
24

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 90 %
Storage relative humidity (H-H)
10 - 90 %
Heat dissipation
114.70 BTU/h

Technical details

Certification
CE mark, CSA (CSA 22.2), FCC 15 (CFR 47), FCC Part 15 (CFR 47) Class A, UL (UL 60950)
Switch type
Managed

Memory

Flash memory
32 MB

Protocols

IPv4 & IPv6 features
IPv6 First Hop Security​ (FHS)
GARP VLAN Registration Protocol (GVRP)
✓
Intra-Site Automatic Tunnel Addressing Protocol (ISATAP)
✓

Data transmission

Number of IP interfaces
256
Number of static routes
2048
Number of queues
8
Throughput
95.24 Mpps

Security

MAC address filtering
✓
IP Source Guard (IPSG)
✓
SSH/SSL support
✓
Broadcast storm control
✓
Static port security
✓
Loop protection
✓
BPDU filtering/protection
✓
DoS attack prevention
✓
IP-MAC-Port binding
✓
Authentication
Guest VLAN, Port-based authentication, Web-based authentication
Root protection
✓
DHCP features
DHCP client, DHCP relay, DHCP server, DHCP snooping

Ethernet LAN features

IP routing
✓

Product Details

Advanced Features for Demanding Environments, at an Affordable Price Your business is growing, and that means more customers, more opportunities, and more attention on your company. The only problem: Your network was built for a smaller operation. As you add more devices, applications, and users, your IT environment will become increasingly difficult and expensive to manage. Even worse, as the network becomes more complex and overloaded, your users are likely to see sluggish performance and even outages. With more customers and employees depending on your business than ever before, a slow or unreliable network is simply not an option. You need an IT backbone that provides excellent performance, nonstop availability, and advanced security. The ideal network will be easy to manage, even as it supports more advanced features, and will be designed to grow with your company. And it is available at a price you can afford. Cisco 500 Series Stackable Managed Switches The Cisco® 500 Series Stackable Managed Switches (Figure 1) are a new line of stackable managed Ethernet switches that provide the advanced capabilities you need to support a more demanding network environment, at an affordable price. These switches provide 24 or 48 ports of Fast Ethernet and 24 to 52 ports of Gigabit Ethernet connectivity with optional 10 Gigabit uplinks, providing a solid foundation for your current business applications, as well as those you are planning for the future. At the same time, these switches are easy to deploy and manage, without a large IT staff. Cisco 500 Series switches are designed to protect your technology investment as your business grows. Unlike switches that claim to be stackable but have elements which are administered and troubleshot separately, the Cisco 500 Series provides true stacking capability, allowing you to configure, manage, and troubleshoot multiple physical switches as a single device and more easily expand your network. The Cisco 500 Series switch offer models which are fanless making it one of the industry’s first in stackable switches, thereby delivering increased reliability, power efficiency, and minimizing noise. A true stack delivers a unified data and control plane, in addition to management plane, providing flexibility, scalability, and ease of use since the stack of units operate as a single entity constituting all the ports of the stack members. The switches also protect your technology investment with an enhanced warranty, dedicated technical support, and the ability to upgrade equipment in the future and receive credit for your Cisco 500 Series switch. Overall, the Cisco 500 Series provides the ideal technology foundation for a growing business.

Files

Product Brochure

mmo_13619408_1487095819_291_4061.pdf

PDF• 763.4 KB

SMB Miercom Report: Managed Stackable Switches Comparison

mmo_13619408_1487095983_9997_4779.pdf

PDF• 1.4 MB

Cisco 500 Series Stackable Managed Switches Administration Guide Firmware Release 1.4.0.x

mmo_13619408_1487096015_4528_4777.pdf

PDF• 7.3 MB

User manual

mmo_34353817_1515584552_9431_9170.pdf

PDF• 1.4 MB

Videos

Portfolio Overview Video

MP4• 8.8 MB
