NETGEAR XS724EM-100NAS 24-ports

Best offer
AED
12 35404

Key Features

  • Switch layer: L2
  • Basic switching RJ-45 Ethernet ports quantity: 24
  • Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
  • DHCP features: DHCP client
  • Store-and-forward: Yes
  • Latency (10 Gbps): 4.16µs
  • Port mirroring: Yes
  • Jumbo frames: 9000
  • SFP+ module slots quantity: 2
  • Switching capacity: 480Gbit/s
  • MAC address table: 32000entries
  • Jumbo frames support: Yes
  • Forwarding rate: 420Mpps
  • IGMP snooping: Yes
  • Form factor: 1U

Specifications

Features

Mean time between failures (MTBF)
830493 h
Quality of Service (QoS) support
Rack mounting
Virtual LAN features
Port-based VLAN
Product colour
Blue, Grey
Packet buffer memory
3 MB
SFP+ module slots quantity
2
Switching capacity
480 Gbit/s
MAC address table
32000 entries
Jumbo frames support
Forwarding rate
420 Mpps
Switch layer
L2

Weight & dimensions

Weight
3720 g
Height
43 mm
Depth
204 mm
Width
440 mm

Power

Power connector
AC-in jack
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Input current
2 A
Power consumption (max)
150.52 W
Power over Ethernet (PoE)

Wireless LAN features

IGMP snooping

Design

Housing material
Metal
LED indicators
Yes
Form factor
1U

Packaging content

User guide
Quick start guide
Manual
Cables included
AC

Network

Networking standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
VLAN support
Number of VLANs
64
Auto MDI/MDI-X
Auto-negotiation
10G support
Link aggregation
Flow control support
Jumbo frames
9000
Port mirroring
Store-and-forward

Ports & interfaces

Basic switching RJ-45 Ethernet ports type
10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity
24

Operational conditions

Operating temperature (T-T)
0 - 50 °C
Operating relative humidity (H-H)
0 - 90 %
Storage relative humidity (H-H)
0 - 95 %
Heat dissipation
513.88 BTU/h

Technical details

Certification
47 CFR FCC, ANSI C63.4:2014, AS/NZS 60950.1:2015 CNS14336-1, AS/NZS CISPR 32:2013, CNS 13438, EN 55024:2010, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, EN 6100-3-3:2013, EN 61000-3-2:2014, EN55032:2012+AC:2013, ICES-003:2016, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, IEC 60950-1:2005(ed.2) + A1:2009 + A2:2013, UL 60950-1, VCCI-CISPR32:2016
Sustainability certificates
ENERGY STAR
Switch type
Managed

Data transmission

Latency (10 Gbps)
4.16 µs

Security

MAC address filtering
Broadcast storm control
DHCP features
DHCP client

Product Details

Unlock your Network Potential with 10-Gigabit/Multi-Gigabit 5-Speed Networking Switches Revolutionary 5-speed 10-Gigabit/Multi-Gigabit technology built in the NETGEAR multi-speed switches allows your devices to speed past the Gigabit barrier. With the growth of virtualization, flash Storage, 4K videos , video streaming and IP surveillance, SMB networks need to extend beyond 1 Gigabit barrier. The 10-Gigabit/Multi-Gigabit Smart Managed Plus series from NETGEAR presents the right solution for this requirement; delivering unprecedented 10-Gigabit/Multi-Gigabit bandwith at an affordable cost. Each port automatically detects which speed is needed by the connected device and provides the adequate speed. As opposed to regular 10-Gigabit switches that will only provide 1-Gigabit connectivity to any device that require less than 10-Gigabit, the XS512EM and XS724EM gives the exact speed required, no downgrade. Also, the new NETGEAR Multi-speed switch ports can be connected with regular Cat5E Ethernet cables, without the need to upgrade to Cat6/Cat6A wiring, therefore reducing wiring costs and hassle
