Allware

Tenda TEG5310P-8-150W 10-ports

Best offer
AED
69900

Key Features

  • Switch layer: L3
  • Basic switching RJ-45 Ethernet ports quantity: 9
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • DHCP features: DHCP relay, DHCP server, DHCP snooping
  • Port mirroring: Yes
  • IP routing: Yes
  • Jumbo frames: 10000
  • Wall mountable: Yes
  • Switching capacity: 20Gbit/s
  • MAC address table: 16000entries
  • Access Control List (ACL): Yes
  • Jumbo frames support: Yes
  • Forwarding rate: 14.9Mpps
  • Multicast support: Yes
  • ARP inspection: Yes

Specifications

Features

Quality of Service (QoS) support
Security algorithms
802.1x RADIUS
Rack mounting
Product colour
Grey
Wall mountable
Switching capacity
20 Gbit/s
MAC address table
16000 entries
Access Control List (ACL)
Jumbo frames support
Forwarding rate
14.90 Mpps
Multicast support
Switch layer
L3

Weight & dimensions

Height
44 mm
Depth
179.60 mm
Width
294 mm

Management features

Web-based management
ARP inspection

Power

Power connector
AC-in jack
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (max)
160 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
130 W

Wireless LAN features

IGMP snooping

Design

LED indicators
Activity, Link, PoE, Power, System
Form factor
1U

Packaging content

Power supply included

Network

Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Management protocols
SNMP V1/V2/V3, Telnet
VLAN support
Ethernet LAN data rates
10, 100
Copper ethernet cabling technology
1000BASE-T, 100BASE-T, 10GBASE-T
10G support
Jumbo frames
10000
Port mirroring

Ports & interfaces

Power over Ethernet (PoE) ports quantity
8
SFP module slots quantity
1
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity
9

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 90 %
Storage relative humidity (H-H)
5 - 90 %

Technical details

Certification
CCC, CE, FCC, RoHS
Switch type
Managed

Protocols

Multicast protocols
IGMP Snooping V1/V2/V3

Security

MAC address filtering
DHCP features
DHCP relay, DHCP server, DHCP snooping

Ethernet LAN features

IP routing

Product Details

TEG5310P-8-150W is a Tenda Layer-3 managed PoE switch. To meet the demand of high-performance access, the switch provides 9 10/100/1000 Mbps Base-T Ethernet ports and 1 separate 1000 Mbps Base-X SFP ports, and a PoE power of up to 130 W.With an innovative hardware structure and software platform, it features a powerful processing capacity and complete security protection mechanism, making management and maintenance easy and simple, fully meeting the demands of high-density user access and high-performance aggregation, ideal for the aggregation layer or access layer of such medium to large networks as enterprises and campuses. L3 Managed PoE Switch Layer-3 Routing Engine,High-Efficiency Fast Forwarding Supports Layer 3 static routing protocols, supports Layer 3 forwarding of up to 400+ terminals, easily meets Layer 3 routing and forwarding across network segments, and truly achieves Layer 2 network isolation and Layer 3 network interworking. Compared with using a Layer 2 switch for transmission, there is no need to go through a router, and the forwarding speed is faster! Map Visualization It supports auto discovery of ONVIF based IP camera and access point, and also supports automatically topology generate. 130W Smart PoE Power Supply It uses a new 150W built-in PoE power supply, and the maximum output power of PoE is 130W. At the same time, the built-in PSE chip with intelligent power management function can monitor the temperature of the chip and customize the PoE power supply based on the time period. The device will automatically turn on / off the PoE function during working hours and idle time to minimize energy consumption and extend the service life of the device. Flexible QoS, Precise Traffic Control The TEG5310P-8-150W supports three QoS scheduling modes (SP, SWRR, WRR) for more accurate traffic control. After the QoS function is enabled, the traffic in the network will be precisely controlled according to the priority of the label. It will prioritize important traffic and reduce the proportion of data flows that occupy a large amount of insignificant traffic in the condition of limited bandwidth,in order to better meet the current transmission needs. Supports Layer 2 And Layer 3 ACL,For More Secure Access Support strict access control based on MAC address or IP address, which can filter the corresponding data packets to enhance user network security. It can be used for network deployment of government, medical and other units. Multiple Attack Defenses, Multiple Securit Blessings Support IP / MAC / ARP filtering / DoS attack protection, enable attack protection according to networking requirements, bring multiple layers of protection to user network security, and ensure network stability and failure-free.
