Elecrow ESP32 Display - Ecran ESP32 5.0 inch 800 x 480

ESP32 Display 5.0 Inch HMI Display 800 x 480 RGB TFT LCD Touch Screen Compatible with Ar Duino/LVGL The ELECROW ESP32 Display 5.0 inch module is a powerful capacitive HMI touch screen with an LCD display with a resolution of 800 x 480. It uses the ESP32-S3-WROOM-1-N4R8 module as the main control processor with a dual-core 32-bit LX6 microprocessor and a main frequency of up to 240MHz, which provides strong performance. Feature 1. Built-in ESP32-S3-WROOM-1-N4R8 module. 2. Support the development environment Arduino IDE, Espressif IDF, Lua RTOS, Micro python and compatible with LVGL graphics library. 3. Built-in LVGL demo interface and Arduino sample, plug and play. 4. LCD 800×480 5.0 inch TFT-LCD capacitive screen with driver IC ILI6122 and ILI5960. 5. Rich peripheral interfaces and expansion features allow it to meet the needs of different areas. Specification Model: 5.0" Wizee ESP32 Display Main processor: ESP32-S3-WROOM-1-N4R8 Resolution: 800 x 480. Colour depth: 16 m. Touch type: capacitive touch screen. Display type: TN panel. Screen: TFT LCD screen. Display driver: ILI6122 or ILI5960 External power supply: DC5V-2A. Interface: 2×UART0,1×GPIO,1×Battery Button: BOOT button and reset button. Active area: 108 x 64.8 mm (W x H). Package list: ESP32 display 5.0 inch module x1. 1 x USB-A to Type-C cable. Crotaill/Grove to 4-pin DuPont cable x 1. 1 x resistive touch pen
