TISTIK ETCR9100B - 33mm

Function: high and low voltage AC leakage current and current online test; online judgment of damp or aging zinc oxide arrester; indirect test of current transformer ratio Power source: DC6V alkaline dry battery (1.5V AAA×4) Measuring range: AC 0.00mA～600A (50/60Hz automatic) Resolution: 10uA Test accuracy: (23℃±5℃, below 80%RH) 0.00mA～100A: ±1%±5dgt 100A～600A: ±2%±5dgt Instrument quality: detector: 335g (including battery), total instrument weight: 2.5Kg (including insulating rod and battery) Instrument size: high pressure detector width and height: 68mm×245mm×40mm Receiver: width, height and thickness 75mm×170mm×30mm Jaw size: φ33mm LCD size: 47mm×28.5mm Insulation rod size: φ32mm, 1m/section (5 sections) Display mode: 4-digit LCD display, backlight function, suitable for dim places Sampling rate: 2 times/sec Test method: Clamp CT, integral method Transmission method: wireless transmission, the maximum distance of linear transmission is about 30m PEAK hold: automatically hold the test value at a high place, usually press the PEAK button in the test mode, the PEAK light is on, that is, the PEAK hold function is turned on, and then press the PEAK button to cancel this function Data retention: Press the HOLD key to hold the data in the normal test mode, the "HOLD" symbol is displayed, and then press the HOLD key to cancel Data storage: 99 groups, the “MEM” symbol indicates during the storage process, the “FULL” symbol flashes to indicate that the storage is full Data access: "MR" symbol indicates, you can scroll up and down the stored data Overflow display: over-range overflow function: "OL A" symbol display No signal indication: when the receiver does not receive the transmitted signal, the "no- -" symbol is displayed dynamically Automatic shutdown: the meter will automatically shut down after about 15 minutes after booting to reduce ba
