Cisco SF11024NA 24-Ports

Key Features

Switch layer: L2
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Number of queues: 4
Fast Ethernet (copper) ports quantity: 24
Jumbo frames: 9216
Queue scheduling algorithms: Weighted Round Robin (WRR)
Switching capacity: 8.8Gbit/s
Full duplex: Yes
MAC address table: 512entries
Jumbo frames support: Yes
Forwarding rate: 3.6Mpps
Form factor: 1U
Auto MDI/MDI-X: Yes
Head-of-line (HOL) blocking: Yes

Specifications

Features

Country of origin

China

Quality of Service (QoS) support

✓

Rack mounting

✓

Product colour

Black

Queue scheduling algorithms

Weighted Round Robin (WRR)

Switching capacity

8.80 Gbit/s

Full duplex

✓

MAC address table

512 entries

Jumbo frames support

✓

Forwarding rate

3.60 Mpps

Switch layer

Packaging data

Package weight

3220 g

Package height

94.10 mm

Package depth

544.80 mm

Package width

297.20 mm

Weight & dimensions

Weight

1930 g

Height

44.50 mm

Depth

440 mm

Width

202.50 mm

Power

Power plug type

Type C

AC input voltage

110 - 240 V

AC input frequency

50 - 60 Hz

Power over Ethernet (PoE)

✗

Design

LED indicators

Yes

Form factor

Packaging content

Quick Start guide

Included power plug types

Quick start guide

✓

Power supply included

✓

Network

Networking standards

IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

Auto MDI/MDI-X

✓

Head-of-line (HOL) blocking

✓

Auto-negotiation

✓

Copper ethernet cabling technology

100BASE-TX, 10BASE-T

10G support

✗

Flow control support

✓

Jumbo frames

9216

Ports & interfaces

Fiber ports quantity

Combo SFP ports quantity

Cable types supported

Cat5, Cat5e, Cat6, Cat6a, Cat6e, Cat7

Fast Ethernet (copper) ports quantity

Basic switching RJ-45 Ethernet ports type

Fast Ethernet (10/100)

Basic switching RJ-45 Ethernet ports quantity

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

10 - 90 %

Storage relative humidity (H-H)

5 - 90 %

Technical details

Certification

CE, CSA, CSA (CSA 22.2), FCC, FCC 15 (CFR 47) A, FCC B, UL, UL (UL 60950)

Switch type

Unmanaged

Data transmission

Number of queues

Security

Loop protection

✓

Logistics data

Harmonized System (HS) code

85176990

Product Details

The Cisco SF110-24 Switch deliver basic network connectivity and reliability for small businesses, without complexity. This switch provides all of the features, expandability, and investment protection you expect from Cisco, with no installation software and nothing to configure. Just plug it in, connect your computers and other business equipment, and get to work.
