Cisco MS225-24P 24-ports

Name: Cisco MS225-24P 24-ports
Brand: Cisco
SKU: 346497
Availability: InStock

Best offer

AED

8 345⁹⁵

Key Features

Switch layer: L2
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
DHCP features: DHCP client, DHCP server
Number of queues: 8
Number of multicast groups filtered: 256
Gigabit Ethernet (copper) ports quantity: 26
Port mirroring: Yes
SFP+ module slots quantity: 4
Switching capacity: 128Gbit/s
MAC address table: 16000entries
Access Control List (ACL): Yes
Multicast support: Yes
Power source: DC/PoE
IGMP snooping: Yes

Specifications

Features

Mean time between failures (MTBF)

391648 h

Internal memory

128 MB

MIB support

Quality of Service (QoS) support

✓

Security algorithms

802.1x RADIUS, SSL/TLS

Rack mounting

✓

Stackable

✓

Product colour

Grey

Packet buffer memory

4.10 MB

SFP+ module slots quantity

Switching capacity

128 Gbit/s

MAC address table

16000 entries

Access Control List (ACL)

✓

Multicast support

✓

Switch layer

Weight & dimensions

Weight

3710 g

Height

43.80 mm

Depth

201 mm

Width

484.60 mm

Management features

Web-based management

✓

Firmware upgradeable

✓

System event log

✓

Number of multicast groups filtered

256

Power

AC input voltage

100 - 240 V

Power consumption (typical)

21 W

AC input frequency

47/63 Hz

Power consumption (max)

882 W

Power over Ethernet (PoE)

✓

Power source

DC/PoE

Wireless LAN features

IGMP snooping

✓

Design

LED indicators

Yes

Form factor

Packaging content

Quick start guide

✓

Cables included

Power supply included

✓

Network

Networking standards

IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x

Management protocols

SNMP v1, SNMP v2, SNMP v3

VLAN support

✓

Number of VLANs

4095

Auto MDI/MDI-X

✓

Spanning tree protocol

✓

Head-of-line (HOL) blocking

✓

Rate limiting

✓

10G support

✗

Link aggregation

✓

Flow control support

✓

Port mirroring

✓

Ports & interfaces

Combo SFP ports quantity

Gigabit Ethernet (copper) ports quantity

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Basic switching RJ-45 Ethernet ports quantity

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

5 - 95 %

Storage relative humidity (H-H)

10 - 90 %

Heat dissipation

64.50 BTU/h

Technical details

Certification

CE, CSA (CSA 22.2), FCC, UL (UL 60950)

Switch type

Managed

Memory

Flash memory

32 MB

Data transmission

Number of queues

Security

MAC address filtering

✓

SSH/SSL support

✓

Broadcast storm control

✓

DHCP features

DHCP client, DHCP server

Logistics data

Harmonized System (HS) code

85176990

Product Details

Cisco 220 Series Smart Switches, part of the Cisco Small Business line of network solutions, are simple, secure and smart switches equipped with enhanced security, management, and performance. Models include 24 or 48 ports of Fast Ethernet, with two Gigabit Ethernet uplinks, and 26 or 50 ports of Gigabit Ethernet connectivity, all with Power over Ethernet (PoE) options. This series of switches provides enhanced capabilities like access control list, command line interface, and PoE+. Offered with limited lifetime warranty, these switches deliver the ideal combination of features, performance, and ease of use to build a fast, reliable and secure business network, at a lower cost than managed switches. - Layer 2 - 24 x 10/100/1000 Ports + 2 x combo Gigabit SFP - Desktop or rack-mountable - 1U - Switching capacity: 38.69 Mpps ¦ Forwarding performance (64-byte packet size): 52 Gbps

Files

Product Brochure

mmo_22791279_1487084026_2931_5814.pdf

PDF• 582.2 KB

Quick Start Guide

mmo_22791279_1487084206_7239_4062.pdf

PDF• 696.6 KB

Cisco 220 Series Smart Plus Switches Administration Guide Release 1.1.0.x

mmo_22791279_1487084257_2312_29956.pdf

PDF• 2.7 MB
