WJYLM Range Hood

Excellent service: If you have any questions, please email us as soon as possible and we will reply you as soon as possible within 24 hours. installation method（It is recommended to ask local professionals for installation） The smoke exhaust pipe is connected to the iron main pipe: 1The main pipe is reserved for a 110mm round mouth, 2The smoke pipe is fixedly connected to the connection reserved mouth. The smoke exhaust pipe is connected to the PVC main pipe: 1The main pipe is reserved for a 110mm tee, 2The tobacco pipe is inserted into the reserved mouth to be sealed by glue or fixed with a flange connection. The smoke exhaust pipe is connected to the 120W fan and the iron main pipe: 1The main pipe is reserved for a 110mm round port, 2the fan is fixed to the iron pipe, the ventilation pipe is connected to the fan outlet, and the flange is fixed with a pipe clamp.The air inlet of the fan is fixed with screws. The exhaust pipe is connected to the 120W fan and the PVC main pipe: 1The main pipe is reserved for a 105mm tee, 2the fan and the roof are fixed with expansion screws, 3the ventilation pipe connects the fan outlet and the pipe reserve, and uses a pipe clamp Fixed, 4The smoke pipe and the fan inlet are fixed with screws. The smoke exhaust pipe is connected to the 90W fan and the PVC main pipe: 1The main pipe is reserved for a 110mm tee, 2The tobacco pipe is inserted into the reserved mouth to be glued or sealed with a flange connection.
