Ubiquiti Wave-LR

Unavailable

Key Features

Antenna gain level (max): 46dBi
Wi-Fi band: Single-band (60 GHz)
Cabling technology: 10/100/1000Base-T(X)
Ethernet LAN data rates: 10, 100Mbit/s
Compliance certificates: CE
Modulation: 1024-QAM, 16-QAM, 256-QAM, 64-QAM, BPSK, QPSK
Product colour: White
Mounting type: Pole
LED indicators: Yes
Power over Ethernet (PoE): Yes
Reset button: Yes
Security algorithms: AES, WPA2-PSK
Rack mounting: No
Power consumption (max): 18W
Ethernet LAN (RJ-45) ports: 1

Specifications

Features

Internal memory

512 MB

Maximum transfer distance

8000 m

Security algorithms

AES, WPA2-PSK

Rack mounting

✗

Product colour

White

Antenna gain level (max)

46 dBi

Weight & dimensions

Weight

2590 g

Height

424.40 mm

Depth

166.20 mm

Width

424.40 mm

Management features

Web-based management

✓

Power

Power consumption (max)

18 W

Power over Ethernet (PoE)

✓

Design

International Protection (IP) code

IPX6

Reset button

✓

Mounting type

Pole

LED indicators

Yes

Network

Wi-Fi

✓

Wi-Fi band

Single-band (60 GHz)

Cabling technology

10/100/1000Base-T(X)

Ethernet LAN data rates

10, 100

Ports & interfaces

Ethernet LAN (RJ-45) ports

Operational conditions

Operating relative humidity (H-H)

5 - 95 %

Technical details

Sustainability compliance

✓

Certification

FCC, ICE

Compliance certificates

Radar

Modulation

1024-QAM, 16-QAM, 256-QAM, 64-QAM, BPSK, QPSK

Product Details

60 GHz PtMP station powered by Wave Technology. Can connect to a Wave AP and deliver 2 Gbps total throughput (1 Gbps duplex). The Wave Long-Range is equipped with a high-performance 5GHz backup radio to ensure uninterrupted connection and a Bluetooth radio to simplify setup via the UISP® Mobile app.

Files

User manual

mmo_107505758_1676474599_9803_32212.pdf

PDF• 4.7 MB

Product Brochure

mmo_107505758_1676474573_0027_32202.pdf

PDF• 931.5 KB

Images

Reviews
