Ubiquiti POE-24-12W-G

Name: Ubiquiti POE-24-12W-G
Brand: Ubiquiti
SKU: 474423
Availability: InStock

Best offer

AED

51⁹⁹

AED

119⁰⁰

-56%

Key Features

Output power: 12W
Power over Ethernet (PoE) voltage: 24V
Surge protection: Yes
Power cord included: Yes
Cabling technology: 10/100/1000
Ethernet interface type: 25 Gigabit Ethernet, Gigabit Ethernet
Ethernet LAN data rates: 10, 100, 1000Mbit/s
RJ-45 input ports: 1
RJ-45 output ports: 1
Remote management port: RJ-45 (Gigabit)
Compliance certificates: BSMI, CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA), PSE, UL
Product colour: Black
Input voltage: 100 - 240 VV
Total Power over Ethernet (PoE) budget: 12W
AC adapter included: Yes

Specifications

Features

Compliance industry standards

EN55022:2010, EN55024:2010, IEC 60950-1:2005+A1, UL60950-1

Plug and Play

✓

Operating temperature (T-T)

32 - 104 °F

Product colour

Black

Weight & dimensions

Weight

99.40 g

Height

33 mm

Depth

29 mm

Width

44 mm

Power

Output current

0.50 A

Power plug type

Type C

Power protection features

Over current, Peak pulse, Surge protection

Input current

0.4 - 0.6 A

Power consumption (max)

0.10 W

AC adapter input voltage

100 - 240 V

Power over Ethernet (PoE)

✓

AC adapter output voltage

24 V

Input frequency

50/60 Hz

AC adapter frequency

50/60 Hz

Input voltage

100 - 240 V

Total Power over Ethernet (PoE) budget

12 W

Output power

12 W

Power over Ethernet (PoE) voltage

24 V

Performance

Surge protection

✓

Other features

Dimensions (WxDxH)

87 x 44 x 33 mm

Design

LED indicators

No, Yes

Packaging content

AC adapter included

✓

Power cord included

✓

Network

Cabling technology

10/100/1000

Ethernet interface type

25 Gigabit Ethernet, Gigabit Ethernet

Ethernet LAN data rates

10, 100, 1000

Ports & interfaces

Ethernet LAN (RJ-45) ports

RJ-45 input ports

RJ-45 output ports

Remote management port

RJ-45 (Gigabit)

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

35 - 95 %

Technical details

Sustainability compliance

✓

Certification

CE, EN55024:2010 FCC Class B, FCC, IC, IEC 60950-1:2005+A1 UL60950‐1 EN55022:2010, UL

Compliance certificates

BSMI, CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA), PSE, UL

Logistics data

Harmonized System (HS) code

85044095

Product Details

PoE Adapters power Ubiquiti® products that support passive PoE. Device Protection PoE Adapters are highly reliable, and when used with Ubiquiti TOUGHCable™, they provide earth grounding and surge protection to help protect against electrostatic discharge (ESD) events. Convenient Wall-Mounting The 24V, 0.5A models, POE-24-12W and POE-24-12W-G, are wall-mountable using the optional wall-mount brackets. Seamless airGateway™ Compatibility The 15V, 0.8A and 24V, 0.5A models, POE-15-12W, POE-24-12W and POE-24-12W-G, work with the airGateway™ to bridge airMAX® connections to Wi-Fi at customer locations.

Files

Product Brochure

mmo_108761106_1675240065_8297_17075.pdf

PDF• 2.8 MB

User manual

mmo_69657479_1601623632_8641_22557

PDF• 2.1 MB
