Signal-to-Noise Ratio (SNR) (panoramic camera): 52dB
Camera tilt control: Yes
Thermal frame rate (PAL): 60 HzHz
Thermal frame rate (NTSC): 50 HzHz
Auto pan mode: Yes
Detect distance: 59m
Observe distance: 25m
Recognize distance: 12m
Camera pan control: Yes
Noise reduction technology: 3D noise reduction
Lens viewing angle, vertical: 61.4°°
Lens viewing angle, diagonal: 34.1–122.8°
Power consumption (Power over Ethernet (PoE)): 12W
Identify distance: 6m
Specifications
Features
Web browser
✓
Protection features
Waterproof
Weatherproof
✓
Screws included
✓
Built-in microphone
✓
Audio formats supported
G.711 A-law
Card reader integrated
✓
Cloud-managed
✓
Maximum memory card size
512 GB
Password protection type
User
Password protection
✓
Video motion detection
✓
Connectivity technology
Wired
Product colour
White
Video streaming
✓
Fixed focus
✓
Alert notification type
Push notification
Type
IP security camera
Active tampering alarm
✓
Mirror
✓
Motion sensor
✓
Sample rate
8 kHz
Audio output channels
1, 2.0
Built-in siren
✓
Supported graphics resolutions
1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520, 320 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA), 704 x 576, 848 x 480
Constant Bit Rate (CBR), Constant Bit Rate (CBR)/Variable Bit Rate (VBR), Variable Bit Rate (VBR)
Region of Interest (ROI) encoding
✓
Total megapixels
4 MP
Number of cameras
1
Zoom capability
✓
Focal length range
2.7 - 13.5 mm
Bit rate
64 Kbit/s
Signal-to-Noise Ratio (SNR)
52 dB
Sensor type
CMOS
Lens viewing angle, horizontal
112.5°
Human and vehicle targets classification
✓
Progressive scan
✓
White balance
Area white balance
Wide Dynamic Range (WDR)
✓
Auto focus
✓
Intelligent Video Surveillance (IVS) system features
Abandoned object, Abnormal sound detection, Intrusion, Line crossing detection, People counting, Region entrance detection, Region exiting detection, Scene change, Vehicle detection
Alarm input/output
✓
Highlight Compensation (HLC)
✓
Digital Wide Dynamic Range (DWDR)
✓
Lens viewing angle, diagonal
34.1–122.8
Lens viewing angle, vertical
61.4°
Camera tilt control
✓
Shutter
Camera shutter type
Electronic
Pan-tilt unit
Tilt angle range
0 - 75 °
Pan range
0 - 360 °
Image sensor
Maximum resolution
2688 x 1520 pixels
Dynamic range
120 dB
Minimum illumination
0.00 lx
Infrared (IR) cut-off filter
✓
Night vision
Number of illumination LEDs
4
Night vision
✓
LED type
IR
Night vision distance
60 m
Infra-red wavelength
850 nm
Panoramic camera
Signal-to-Noise Ratio (SNR) (panoramic camera)
52 dB
Sensor type (panoramic camera)
CMOS
Product Details
See True Colors and Details in the Dark
Unveiling every detail in the dark, experiencing clarity and color as vivid as daylight — no extra fill lights needed.
Worry-Free Night Surveillance: Beyond IR & Full-Color
Eliminates general night vision issues like dark corners, glare, and color loss — enjoy worry-free nighttime monitoring.
See Vividly — Even No Extra Fill Lights Needed
Enables full-color imaging in low-light conditions without fill-in lighting, reducing both energy consumption and insect-triggered false alarms for a more eco-friendly solution.
People or Vehicle Triggered Intelligent IR-White Lights Reveal More in Total Darkness
In complete darkness with zero illumination, VIGI’s intelligent infrared-white lights will automatically activate white lights upon detecting people or vehicles, delivering vivid color imaging while deterring intruders.
Accurate Detection with Clear and Extended VisionIdeal for Low-Light Conditions Where Colors and Details MatterVIGI AI Detection Technology
People & Vehicle Attributes Analytics: Search and filter to people or vehicle of interest based on many different attributes, like hair length, topwear color, vehicle type, making post-event search faster and easier
Human & Vehicle Classification: Distinguish humans and vehicles from other objects, such as moving animals, falling leaves, changing lights, and receive more accurate event notifications
Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
