Wireless O Wireless Mode: IEEE 802.11b/g/n (Wi-Fi 4), AP, Client (STA), Mesh (802.11s), Multi AP O Wi-Fi Security: WPA-PSK, WPA2-PSK, WPA3-SAE, WPA-EAP, OWE, WPA2-EAP, WPA3-EAP O SSID/ESSID: ESSID stealth mode O Wi-Fi Users: Up to 50 simultaneous connections O Wireless Features: Mesh (802.11s), Fast Roaming (802.11r), Relayd, BSS transition (802.11v), RRM (802.11k) O Wireless MAC Filter: Allowlist, Blocklist O Wireless QR Code: Auto-connect without inputting login credentials O TravelMate: Forward hotspot landing page to subsequent device Ethernet O LAN: 2 x LAN ports, 10/100 Mbps O Standards: IEEE 802.3, 802.3u, 802.3az, Auto MDI/MDIX crossover Network O Routing: Static, BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP, Policy-based routing O Network Protocols: TCP, UDP, IPv4/IPv6, NTP, DNS, HTTP/S, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SNMP, MQTT, WOL O VoIP Passthrough: H.323 and SIP-alg NAT helpers O Connection Monitoring: Ping Reboot, Wget Reboot, Periodic Reboot, LCP, ICMP O Firewall: Port forward, traffic/custom rules, firewall status page O Ports Management: Enable/disable ports, auto-config, transmission speed O Network Topology: Visual connection mapping O DHCP: Static/dynamic allocation, relay, static leases with MAC wildcards O QoS / SQM: Source/destination, protocol, service, WMM, 802.11e O DDNS: >25 providers supported O DNS over HTTPS: Secure DNS resolution over HTTPS O Network Backup: Wi-Fi WAN, VRRP, Wired failover O Load Balancing: Across multiple WANs O Hotspot 2.0: Seamless, secure Wi-Fi roaming O SSHFS: Remote file system via SSH O VRF Support: Initial support Traffic Management O Real-time Monitoring O Wireless Signal Charts O Traffic Usage History Security O Authentication: Pre-shared key, X.509, TACACS+, RADIUS (Int./Ext.), IP/login blocking, time-blocking, random password generator O Firewall: Preconfigured via WebUI, full via CLI, DMZ, NAT, NAT-T, NAT64 O Attack Prevention: DDoS (SYN flood, SSH, HTTP/S), Port scan (SYN-FIN, SYN-RST, X-mas, NULL, FIN) O VLAN: Port/tag-based separation O Web Filter: Blacklist/Whitelist O Access Control: SSH, WebUI, CLI, Telnet O SSL Certificate: Let’s Encrypt, SCEP VPN O OpenVPN: Multiple client/server, 27 encryption methods O OpenVPN Encryption: DES, RC2, 3DES, AES (128/192/256), Blowfish, CAST5 O IPsec: IKEv1/v2, XFRM, 14 encryption methods (3DES, AES, GCM variants) O GRE: GRE tunnel + GRE over IPsec O PPTP/L2TP: Simultaneous client/server, L2TPv3, L2TP over IPsec O Stunnel: TLS encryption wrapper O DMVPN: IPsec VPN with Phase 2/3, dual hub O SSTP: Client instance O ZeroTier: Client support O WireGuard: Client and server O Tinc: Client/server with encryption/auth/compression O Tailscale: P2P over WireGuard OPC UA O Supported Modes: Client, Server O Connection Types: TCP MODBUS O Supported Modes: Server, Client O Connection Types: TCP, RTU (RS232) O Custom Registers: MODBUS TCP read/write from internal file O Data Formats: O 8-bit: INT, UINT O 16-bit: INT, UINT (MSB/LSB first) O 32-bit: float, INT, UINT (ABCD, DCBA, CDAB, BADC), HEX, ASCII Data to Server O Protocols: HTTP(S), MQTT, Azure MQTT O Features: Multi-source extraction, LUA scripting MQTT Gateway O MODBUS MQTT Gateway: Command/data exchange via broker DNP3 O Modes: Station, Outstation O Connection: TCP, RTU (RS232) DLMS/COSEM O DLMS Mode: Client O COSEM: Object scan and config O Connection: TCP, RTU (RS232) API O Teltonika Web API (beta): Retrieve/change data using endpoints Monitoring & Management O Web UI: HTTP/S, FW updates, logs, troubleshooting, event logs O FOTA: Firmware from server O SSH: v1, v2 O Email: Alerts and service updates O TR-069: OpenACS, GenieACS, FreeACS, etc. O MQTT: Broker & publisher O SNMP: v1, v2, v3, Traps, brute force protection O JSON-RPC: Management API over HTTP/S O MODBUS: TCP status/control O RMS: Teltonika Remote Management System IoT Platforms O ThingWorx O Cumulocity (Cloud of Things): Monitor, reboot, FW update O Azure IoT Hub: Full data send, Direct method API, zero-touch provisioning O AWS IoT Core: Cloud interaction, API calls via Jobs System Characteristics O CPU: Mediatek 580 MHz, MIPS 24KEc O RAM: 128 MB DDR2 O Flash Storage: 16 MB NOR Firmware / Configuration O Web UI: Update via file/server, backup, config profiles O FOTA: Multi-device update O RMS: Central config/update O Keep Settings: FW update without loss O Factory Reset: Complete system restore Firmware Customisation O OS: RutOS (OpenWrt-based Linux) O Languages: Busybox (ash), Lua 5.1, C, C++ O SDK: Provided for custom firmware O GPL Customization: Colors, logos, branding O Package Manager: For installing extra software Serial O RS232: TX, RX, RTS, CTS (Terminal block) O Serial Functions: Console, Serial-over-IP, Modem, MODBUS Gateway, NTRIP Client Power O Connector: 3-pin terminal block O Input Voltage: 9–30 VDC O Protections: Reverse polarity, surge >31V O PoE Passive: Over LAN2 port (Mode B, 9–30 VDC) O Power Consumption: Idle <1 W / Max <2 W Physical Interfaces O Ethernet: 2 x RJ45 ports, 10/100 Mbps O LEDs: 2 x LAN LEDs, 1 x Power LED O Power: 1 x 3-pin power connector O Antenna: 1 x RP-SMA Wi-Fi O RS232: 1 x DB9 socket O Reset: Reboot, user default, full factory reset O Grounding: 1 x screw Physical Specification O Material: Aluminium housing O Dimensions (W x H x D): 113.10 x 25 x 68.6 mm O Weight: 149.2 g O Mounting: DIN rail, wall, flat (optional kit) Operating Environment O Temperature: -40 °C to 75 °C O Humidity: 10% to 90% (non-condensing) O Ingress Rating: IP30 Regulatory & Approvals O Certifications: CE, UKCA, CB, FCC/IC O RF Standards: Wi-Fi (2.4 GHz, 5 GHz) – 47 CFR Part 15 Subpart C § 15.247
